Automatic case erector for cartonboard with hot-melt glue binding

Streamline your packaging line with efficient case erecting and secure bottom flap closure using precise hot-melt technology, ensuring consistent, high-speed operation for bottling or food production facilities aiming to enhance their automation process.

Automates Case Erecting, Packing, and Sealing

The Productive Series from APE Impianti transforms packaging operations within the wine, beer, spirits, and food industries by fully automating case erecting, packing, and sealing processes. The series includes the FORM 1300, AXIPACK 100, INCA BS, AXI INSER 100, CH S11 NS, and CH 1000, each designed for specific tasks like erecting American RSC cartons with hot-melt closure, or modular packing using brushless motor-driven axes for precise control.

Capable of handling up to 6,000 bottles per hour, these machines streamline the packaging of 250ml to 750ml bottles, including returnable glass. Integration into existing lines is seamless, with format changes and remote control available through advanced operator panels. The AXIPACK 100’s modular design adapts to spatial constraints, while all models emphasize energy efficiency and robust construction.

Compliance with industry standards ensures quality and reliability, while the easy-to-maintain components, like the vacuum suction heads in the INCA BS, preserve bottle integrity and simplify cleaning. Tailored engineering support is available for customization, maximizing operational uptime and production flexibility.

Benefits

  • Enhances packaging efficiency by automating case setup and sealing, reducing manual labor.
  • Increases production flexibility with quick format changes, adaptable to varying bottle and carton sizes.
  • Optimizes space utilization with modular design tailored to existing production lines.
  • Minimizes bottle damage while ensuring label preservation with gentle packing mechanisms.
  • Reduces energy consumption through precise motor control, lowering operational costs.

General


Applications
Food,Glass return bottles,Wine,Cartons,Spirits,Beer
End products
Beer bottles,Wine bottles,Packaged food items,Spirit bottles,Returnable glass bottles,Cardboard cartons
Steps before
Bottle Filling,Labeling,Bottle Sealing
Steps after
Carton Sealing,Palletizing,Distribution
Input ingredients
RSC-AMERICAN cartonboard,plastic crates,bottles,cartons,cardboard divider
Output ingredients
sealed cartons,packed bottles,closed cartons,horizontal bottles
Market info

Technical Specifications


Speed
Up to 6,000 bottles/hour
Automation level
Full automation
Case Erection
Automatic
Glue Type
Hot-melt
Modularity
Fully modular
Motor Type
Brushless motors
Control
Maximum control in every packaging cycle
Format Change
Automated
Case Handling
RSC-AMERICAN cartonboard

Operating Characteristics


Working mechanism
Brushless motor with linear axes
Automation level
Fully automated with operator panel control
Batch vs. continuous operation
Continuous
Changeover time
Fast,automated format changes
Handling control precision
Highly precise,available in "PLUS" version
Flexibility
Modular design for space and requirements adaptability
Packaging configuration
Case packer with crate kit for plastic crates
Robotic system
2 linear axes with vacuum suction head
Hot-melt glue system
Available for closing flaps

Product type Characteristics


Container type
Cartonboard / Plastic Crates
Flexibility
Modular / Fast format change

Physical Characteristics


Carton style
RSC-AMERICAN
Control panel type
Operator panel
Discharge method
Hot-melt glue

Custom Options


Control panel type
Operator panel with format change options
Modular design
AXIPACK technology,modular adjustments for space and requirements
Configuration ability
Allows for the addition of crate kits and other custom modules
Robotic system customization
INCA BS with vacuum suction heads and carton dividers
Adhesive options
Hot-melt glue or adhesive tape sealing
