Wet wipe converting line

Optimize your production with a versatile and precise solution designed for high-quality wet wipe manufacturing, ensuring minimal waste and seamless integration into your existing operations.

Converts, Folds, and Packages Wet Wipes

The GENESIS Wet Wipe Converting Line from the IMA Group is a highly reliable system tailored for producing a diverse range of wet wipes, from baby wipes to industrial cleaning wipes. It seamlessly integrates folding, cutting, wetting, sealing, splicing, labeling, and packing, all within a continuous, high-speed operation. Engineered with flexibility in mind, it handles up to 12 pre-cut rolls with options for manual or automatic splicing. The system’s individual wetting stations ensure precise and uniform liquid distribution, crucial for maintaining product quality. Preserving efficiency, GENESIS minimizes waste to less than 3%, requiring only one to two operators, thereby lowering operational costs. The fully servo-controlled design and ATEX compliance enhance safety and performance when using flammable liquids. For ease of maintenance, it includes a CIP system, facilitating quick changes and minimizing downtime. This makes GENESIS ideal for start-ups and small-scale producers aiming for multiple daily changeovers without compromising on quality or efficiency.

Benefits

  • Enhances production efficiency with a waste rate of less than 3%.
  • Lowers operational costs by requiring only 1-2 operators for full operation.
  • Complies with global sanitary standards, minimizing contamination risks.
  • Flexibly accommodates multiple product changeovers, ideal for small lot productions.
  • Ensures product safety with ATEX compliance for handling flammable liquids.

General


Applications
Nonwoven products,Personal care products,Hygiene products,Home care products,Wet wipes
End products
Facial cleansing wipes,Lens cleaning wipes,Baby wipes,Antibacterial wipes,Moist toilet tissues,Makeup remover wipes,Disinfectant wipes,Allergy relief wipes,Surface cleaning wipes,Industrial cleaning wipes
Steps before
Material Sourcing,Roll Slitting,Lotion Preparation,Film Unwinding
Steps after
Packing,Labelling,Sealing,Quality Control
Input ingredients
pre-cut rolls,flim rolls,isopropyl alcohol,flammable liquids,lotion
Output ingredients
wet wipes,packs of wet wipes
Market info
IMA is known for its expertise in manufacturing automated packaging machines and solutions, particularly for the pharmaceutical, cosmetics, food, tea, and coffee industries, offering innovative, high-quality equipment and comprehensive customer service.

Technical Specifications


Design speed
up to 6000–7200 wipes/min
Operating speed
up to 5000–6000 wipes/min
Cutting speed
500 clips/min
Stacking speed
120 stacks/min
Linear speed
100 m/min
Packing machine speed
100 packs/min | 80 with gusset
Rolls – Precut
10/12
Drive System
Full Servo
Roll diameter
1200–1500 mm
Roll width
150–290 mm
Stack length
100–320 mm
Folded wipe width
75–120 mm
Interfolded
Yes/No
Fold type
Z,C,W,modified V
Reels splice
Manual/Automatic
Clip height
5–20 mm
Stack height
5–80 mm
Quantity of lotion
200–350%
Labelling machines
2–3
Sealing of wrapping machine film
Automatic
Sealing head
Long Dwell Technology
Waste
< 3%

Operating Characteristics


Working mechanism
Length-fold wet wipes converting
Integration level
Integrated flow wrapper with film unwinder,die cut,labellers,lot printer,feeding,folding,sealing unit
CIP principles
CIP ready,allows for easy and effective Cleaning In Place
Batch vs. continuous operation
Continuous inline
Automation level
Full Servo,high-level automation with HMI
Efficiency
High efficiency,waste minimized to <3%
Changeover flexibility
Recipes in HMI for quick retrieve and error proof operation
Sanitary compliance
Complies with worldwide sanitary standards

Material Compatibility


Corrosive resistance (e.g. acids)
Stainless steel components
Cleanability
CIP (Clean In Place) capability

Product type Characteristics


Wet wipe format
Z,C,W,modified V fold
Wipe size
Up to 300mm length
Material type
Nonwoven
Lotion compatibility
Isopropyl Alcohol (IPA),flammable liquids

Physical Characteristics


Machine Layout
GENESIS 10 / GENESIS 12
Machine Footprint
5 m length
Roll Diameter (mm)
1200 | 1500
Roll Width (mm)
150 | 250 | 290
Stack Length (mm)
100 | 320
Folded Wipe Width (mm)
75 | 120
Clip Height (mm)
5 | 20
Stack Height (mm)
5 | 80
Rolls – Precut
10 | 12
Fold Type
Z,C,W,modified V
Drive System
Full Servo

Custom Options


Control panel type
HMI
Integration possibilities
Integrated flow wrapper
Reels splice
Manual / Automatic
Roll diameter option
1200 mm | 1500 mm
Roll width option
150 mm | 250 mm | 290 mm
