Single shaft screw feeders for consistent material feeding

Tackle challenging materials with poor flow characteristics by optimizing feed rates and preventing blockages, ensuring efficient downstream processing through precise single shaft screw feeder technology.

Feeds and Conveys Powders and Granules Efficiently

The Single Shaft Screw Feeders SU from WAMGROUP offer a robust solution for efficiently feeding and conveying powders and granules, particularly in challenging conditions. These feeders are meticulously designed to prevent common flow issues such as bridging, rat-holing, and segregation, ensuring consistent material processing. Ideally suited for the production of flour, animal feed, paint, and varnish, these feeders are crucial in maintaining steady material supply lines. With a modular design, they integrate seamlessly into various production processes and can handle continuous and manual operations efficiently.

Available in both standard U-shaped and flared V-section troughs, the SU feeders are offered in light-duty versions for materials like flour and heavy-duty versions for animal feed. Constructed with carbon steel and featuring a durable powder-coated finish, the equipment can withstand rigorous workplace conditions. The system is equipped with ATEX Zone 22 certification, highlighting its safety for use in potentially explosive environments.

Integration is made easy with options for direct drives or chain and belt transmission systems, and it supports a wide range of outlet configurations. Maintenance is minimized with features like self-lubricating slide bush bearings, ensuring longevity and reliability in demanding industrial applications. Customization options, such as food-grade finishes and air-purged shaft seals, allow further tailoring to specific operational requirements.

Benefits

  • Ensures continuous material flow, reducing the risk of production interruptions.
  • Customizable configurations enhance adaptability across diverse production environments.
  • Robust construction minimizes maintenance needs, lowering operational costs.
  • Certified for safety in explosive atmospheres, ensuring compliance and worker protection.
  • Improves material handling efficiency, preventing costly bridging and segregation issues.

General


Applications
Animal feed,Fish food,Paint,Varnish,Flour,Petfood
End products
Oil-based paint,Dog kibble,Pastry flour,Cat chow,All-purpose flour,Acrylic paint,Bread flour,Fish pellets,Polyurethane varnish,Wet canned dog food,Water-based varnish
Steps before
Material Storage,Material Handling,Sizing
Steps after
Mixing,Packaging,Transportation
Input ingredients
powders,granular materials,flour,animal feed,materials with similar bulk density
Output ingredients
efficient material feeding,processed materials
Market info
WAMGROUP is known for its expertise in manufacturing bulk material handling and processing equipment, including screw conveyors, dust collectors, and valve systems, with a strong reputation for innovation, quality, and global market presence.

Technical Specifications


Feed rate
50–1000 kg/h
Automation
Direct drives in a compact version,with coupling transmission,or with chain or belt transmission
Shaft coupling
Splined or bolted
Capacity
Light or medium-heavy-duty
Trough type
U-shaped or flared V-section
Construction material
Carbon steel
Seals
Manually adjustable packing gland seals
Drive type
Direct drives with coupling transmission,chain or belt transmission
Bearing type
Maintenance-free intermediate cast hanger bearings with self-lubricating slide bushes
Powder-coating
Yes
Certifications
ATEX,Zone 22

Operating Characteristics


Feed rate consistency
Constant
Modular design
Enabling easy access
Material flow improvement
Prevents bridging,rat-holing,or segregation
Material feeding mechanism
Single shaft screw mechanism
Custom-design features
Available
Drive unit position
Mounted at inlet or outlet end
Shaft couplings
Splined or bolted
Transmission type
Direct,coupling,chain or belt

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm


ATEX certification
Zone 22

Physical Characteristics


Machine footprint
Modular design
Feed/Discharge method
Open trough section with drilled WAM standard trough flange
Shape
Standard U-shaped or flared V-section trough
Main Body Material
Light or medium-heavy-duty carbon steel

Custom Options


Modular design
Enabling easy access and individual custom-design features
Drive unit type
Direct drives / Coupling transmission / Chain or belt transmission
Outlet spout options
Square,rectangular,or shoe-type with drilled WAM standard flanges
Finishing and painting
Food-grade
ATEX Certification
Zone 22
Seals
Air-purged shaft seals
