Isobaric filling system for carbonated beverages in Pet bottles

Achieve precise carbonation levels and seamless integration with your existing production line, minimizing downtime with quick changeovers and ensuring high-speed, efficient filling for a wide range of beverages, from sparkling waters to isotonic drinks.

Fills and Pressurizes Carbonated and Non-Carbonated Beverages

The Isofill P from SIPA is an advanced isobaric filling machine designed for efficient and precise carbonation of PET bottled beverages. This mechanical level filler offers a unique solution for beverage manufacturers, accommodating carbonated and non-carbonated products while ensuring minimal oxygen uptake and optimal product integrity.

Key features include a stainless-steel filling valve with height adjustment for flexible level control, reducing product waste and downtime during changeovers. It seamlessly processes carbonated soft drinks, still mineral water, cold filled juices, isotonic beverages, and beers. The Isofill P can manage an output of 3,900 to 30,000 bottles per hour, depending on configuration, making it suitable for high-speed operations.

The machine integrates effortlessly into existing production lines with its Sincro Bloc configuration for combined blowing, filling, and capping processes. Enhanced hygiene is maintained through an easily sanitized system with optional cap sterilization, while automatic dummy bottle engagement ensures hands-free operation, reducing the risk of contamination.

Constructed from robust AISI 316 stainless steel, the Isofill P is engineered for durability and compliance with rigorous industry standards, featuring full compatibility with high-temperature cleaning processes. SIPA also offers customization and engineering support to tailor the Isofill P to specific production needs, ensuring a seamless fit into diverse operational environments.

Benefits

  • Enhances production speed with throughput up to 30,000 bottles per hour.
  • Minimizes product waste through precise filling level control.
  • Streamlines changeovers to reduce downtime and increase line efficiency.
  • Ensures high hygiene standards with automated cleaning processes.
  • Integrates seamlessly into existing lines with its modular Sincro Bloc setup.

General


Applications
Cold filled isotonic drinks,Clear cold filled juices,Sport drinks,Carbonated soft drinks (csd),Still mineral water,Carbonated mineral water,Beer
End products
Electrolyte sports drink,Still spring water,Lager beer,Orange juice,Lemon-lime soda,Ale beer,Lemon iced tea,Sparkling water,Energy drink,Cola
Steps before
Bottle production,Preform moulding,Blow moulding,Pre-evacuation
Steps after
Capping,Labeling,Secondary packaging,Palletizing
Input ingredients
carbonated beverages,carbonated soft drinks (CSD),still mineral water,clear cold filled juices,cold filled isotonic drinks,sport drinks,beer,PET bottles
Output ingredients
filled PET bottles,carbonated mineral water,carbonated soft drinks (CSD),still mineral water,clear cold filled juices,cold filled isotonic drinks,sport drinks,beer
Market info

Technical Specifications


Automation
Automatic
Material
AISI 316 stainless steel
Bottle Capacity
0.125 to 3000 ml
Output Capacity
3,900 to 30,000 b/hour
Bottle Type
PET
Filling Valve Type
Mechanical level valve
Filling Method
Isobaric filling
Temperature Capability
Ambient temperature filling
Valve Adjustment
Height adjustable moving filling tube
Sanitation Cycle
Automatic
Changeover Down-time Reduction
Quick changeover
Valve Quantity
20 to 140 valves
Decompression System
Centralized control
Dummy Bottles
Automatically engaged

Operating Characteristics


Batch vs. continuous operation
Inline Continuous
Foam reduction solutions
Ambient temperature operation
Changeover time
Reduced
Automation level
Electro-pneumatic control
Cleaning method
Automatic CIP
Sanitation process
Fully automatic

Material Compatibility


Corrosive resistance (e.g. acids)
Yes
Cleanability
Easy to sanitize
Abrasion resistance
High
Biological compatibility
High

Product type Characteristics


Container type
PET bottles
Container size
0.125 to 3,000 ml
Carbonation compatibility
Carbonated and non-carbonated beverages
Temperature sensitivity
Ambient temperature
Hygiene and sanitation
Fully automatic sanitation

Physical Characteristics


Tank shape and size
Central stainless steel tank
Feed/discharge method
PET bottle transfer - neck-handling
Control panel type
Operator panel

Custom Options


Control panel type
Electro-pneumatic control
Integration possibilities
Sincro Bloc configuration for integrated blowing-filling-capping
Container size adaptability
PET Bottles from 0.125 to 3000 ml
Filling tube position adjustment
Centralized control for simultaneous adjustment
Hygiene integration
Controlled contamination cabin and cap sterilizing unit available
