Industrial vacuum stuffer for high-volume food production
Streamline your sausage production with precision filling and portioning, achieving seamless linking for a wide range of products like bratwurst and salami, ensuring consistency and efficiency in high-demand environments.
Fills, Portions, and Links Meat Products
The F-LINE F103 Vacuum Stuffer by Heinrich Frey Maschinenbau is engineered for precision in the meat and sausage production industry. This fully electronic vacuum stuffer features a digitally-controlled system, ensuring seamless operation for continuous filling, portioning, and linking. Capable of handling up to 3,000 kg/h, it is perfect for producing delicatessen items such as pâté, bratwurst, and salami with exact portion sizes ranging from 5 to 100,000 grams. The sturdy stainless steel construction ensures durability, while the 120-liter hopper and 55-bar filling pressure facilitate efficient processing. Integrating the F-LINE F103 into your line is straightforward, with its Ethernet and USB interfaces supporting easy connectivity. It’s equipped with the FREY TC 266 touch control for intuitive operations, offering programmable settings for diverse product requirements. The machine’s energy-efficient design, customized voltage options, and servo linker for high-speed linking precision make it a reliable choice for industrial food manufacturers focused on quality and productivity.
Benefits
- Increases production efficiency with continuous, high-speed operation.
- Ensures consistent product quality with precise portion control.
- Simplifies integration and reduces setup time with easy connectivity options.
- Decreases energy consumption with optimized motor control and servo linker.
- Minimizes maintenance costs with durable stainless steel construction.
- Applications
- Cooked sausages,Meat products,Kebap,Sausages,Delicatessen
- End products
- Currywurst,Pepperoni,Weisswurst,Luncheon meat,Pâté,Bologna sausage,Bratwurst,Salami,Sucuk,Mettwurst
- Steps before
- Grinding,Preparation
- Steps after
- Linking,Packing
- Input ingredients
- meat,mixture,dough
- Output ingredients
- portioned meat,linked sausage,stuffed casings
- Market info
- Frey Maschinenbau is known for manufacturing high-quality, engineered-to-order industrial equipment, specializing in innovative solutions and precision engineering. They have a strong reputation for reliability and customer-focused service in the industrial machinery market.
- Filling Capacity
- Up to 3,000 kg/h
- Filling Pressure
- Max. 55 bar
- Vacuum Pump
- 21 m³/h
- Total Connected Load
- Max. 10.5 kW
- Rotary Current
- 400 Volt,50 Hz,3-phase
- Special Voltages
- 200 - 480 Volt possible
- Display
- 8.4 inch TFT color display (800 x 600 pixels)
- Portioning Range
- 5 - 100,000 g (5 - 999 g in 0.1 g increments)
- Portioning Speed
- Max. 600 portions/min
- Machine Housing and Hopper
- Stainless steel,one-piece hopper,approx. 120 liters
- CAN Bus for Communication
- High-speed communication with attachments
- Hopper Capacity
- Approx. 120 liters
- Error Display and Memory
- Memory for 200 filling programs,including cooked sausage programs
- Control System
- FREY TC 266 touch control (TC 733 optional)
- Self-explanatory Operation
- Intuitive operation by touching the display
- Working mechanism
- Fully electronic,continuous
- Integrated steps
- Filling,portioning,linking
- Automation level
- Industrial PC control
- Flow measurement
- Included
- Portioning range
- 5 - 100,000 g
- Portioning speed
- Max. 600 portions/min
- Error display
- Included
- Filling pressure
- Max. approx. 55 bar
- Vacuum system
- Digitally-controlled
- Energy efficiency
- 10.5 kW total connected load
- Batch vs. continuous operation
- Continuous
- Abrasion resistance
- Yes
- Biological compatibility
- Food grade
- Cleanability
- Stainless steel construction
- Corrosive resistance (e.g. acids)
- Yes
- Hopper Size
- 120 liters
- Material
- Stainless Steel
- Filling Pressure
- Up to 55 bar
- Power Supply
- 400 Volt,50 Hz,3-phase
- Control panel type
- FREY TC 266 touch control / TC 733 optional
- Integration possibilities
- Ethernet interface,USB interface,CAN bus for high-speed communication
- Power options
- 400 Volt,50 Hz,3-phase or special voltages 200 - 480 Volt
- Portioning range customization
- 5 - 100,000 g in 0.1 g increments
- Portioning speed customization
- Max. 600 portions/min
