Industrial coffee grinder for ground coffee production

Enhance your coffee production line with precise grinding capabilities, customizable granulometry, and an efficient degassing system to preserve aroma and quality at every stage.

Grinds and Degasses Coffee for Packaging

The Grinder 1000 from Scolari Engineering stands out as a comprehensive solution for coffee processing facilities. Utilizing a modular structure with self-cleaning magnet protection, this grinder efficiently processes roasted coffee into espresso and moka grounds. Its unique advanced inert gas environment minimizes maintenance and enhances the longevity of the ground coffee by reducing oxidation. The unit operates using hard centrifuged cast iron rollers with an excellent thermal exchange system, controlled by onboard sensors for precise granulometric outcomes. Ideal for high-speed, continuous operations, it offers a high processing capacity of up to 1,500 kg/h for moka coffee grounds. Fully automated with computer-controlled grinding settings, the machine integrates seamlessly into conveying systems with chain, vacuum, and dense phase conveyors, feeding degassing silos that connect to vacuum packing operations. Constructed for durability, it features sound-proof external panels, ensuring quieter operation. Designed with energy efficiency in mind, it incorporates customizable density settings through a servo-motor-managed compactor, meeting diverse production demands.

Benefits

  • Enhances production efficiency with high-capacity grinding, handling up to 1,500 kg/h.
  • Preserves coffee quality by minimizing oxidation with inert gas operation.
  • Reduces maintenance needs through self-cleaning design and robust construction.
  • Customizable grind density settings ensure product consistency and quality.
  • Seamless integration into existing systems improves overall production line flow.

General


Applications
Ground coffee,Roasted coffee
End products
Moka coffee grounds,Espresso coffee grounds
Steps before
Roasting,Grinding,Feeding
Steps after
Degassing,Vacuum Packing,Density Adjustment
Input ingredients
green coffee beans,roasted coffee beans,compressed air
Output ingredients
ground coffee
Market info
Scolari Engineering is known for designing and manufacturing custom-engineered drying systems and equipment, particularly for the food and agricultural industries, leveraging innovative technology and a strong reputation for quality and reliability.

Technical Specifications


Capacity
ESPRESSO
MOKA
kg/h 1500 Lbs/h 3306
Dimensions
Length 2600 mm,Width 1600 mm,Height 3200 mm
Weight
5000 Kg
Pressure
6 bar
Roller Material
Very hard centrifuged cast iron
Thermal Exchange
Excellent with thermostat
Automation
Totally computerised grinding regulation
Control Panel
Control of motors absorption,rollers gap,cooling liquid temperature,feeder speed and position of loading and unloading
Compressed Air Usage
Pressure 6 bar

Operating Characteristics


Automation level
Computerised grinding regulation
Batch vs. continuous operation
Batch
Cleaning method
Low maintenance required
Control features
Control of motors absorption,rollers gap,cooling liquid temperature,feeder speed
Degassing method
Sealed degassing system utilizing inert gas
Granulometric control
Customizable granulometric spectrum
Modular structure
Modular structure with individual levels

Material Compatibility


Abrasion resistance
High (Rollers made of very hard centrifuged cast iron)
Corrosive resistance (e.g. acids)
Moderate (Stainless steel cooling room)

Physical Characteristics


Machine Footprint
Length 2600 mm,Width 1600 mm,Height 3200 mm
Weight
5000 Kg
Control Panel Type
On-board control panel
Discharge Method
Computerized grinding regulation with customised unloading point

Custom Options


Control panel type
Computerised control panel with synoptic display
Customization of grinding settings
Granulometric spectrum customization
Modular structure
2 individual modular levels (+1 optional)
Roller material
Very hard centrifuged cast iron
Density adjustment
Density can be changed using a servo-motor
