High capacity seed dedusting and conditioning system

Achieve optimal seed quality with a high-capacity system that seamlessly integrates into your existing treatment line, ensuring efficient dedusting and conditioning for enhanced product performance.

Dedusts and Conditions Treated Seeds

The RFBC800 from Hoopman Equipment & Engineering is a compact, efficient solution designed for dedusting and conditioning treated seeds directly after processing. Its integration-friendly design allows it to seamlessly fit into existing treatment systems, addressing the needs of high-capacity seed treatment operations. This conditioner features a capacity range of 4-8 tons per hour, specifically optimized for wheat seeds, making it suitable for a variety of agricultural applications.

Equipped with both manual and automated PLC controls, the RFBC800 offers flexibility in operation and is customizable to suit specific capacity, humidity, and process variables. It offers multiple air conditioning options and a cooling section, with optional air cooling units to ensure precise conditioning according to the seed treatment processes. The unit’s compact size doesn’t compromise performance, providing scalable solutions and real-world testing to tailor the system to your specific needs.

Ideal for seed processors seeking a reliable and efficient post-treatment conditioning solution, the RFBC800 is designed to integrate smoothly into your operations with minimal disruption, ensuring optimal seed quality-and handling.

Benefits

  • Increases seed quality and productivity by seamlessly integrating with existing systems.
  • Minimizes labor requirements with optional PLC-controlled, automated operation.
  • Tailors to specific needs with customizable capacity and humidity control options.
  • Optimizes operational efficiency with scalable throughput of up to 8 tons per hour.
  • Adapts to various processing variables, enhancing flexibility and precision in conditioning.

General


Applications
Seed treatment equipment,Agricultural products,Plant conditioning,Coating materials,Seeds
End products
Plant conditioning solutions,Wheat seeds,Seed pellets,Seed priming agents,Treated seeds,Seed coating
Steps before
Seed Treating,Rotary Coating
Steps after
Drying,Cooling,Automated Coating/Drying
Input ingredients
treated seeds,unconditioned seeds,high humidity seeds
Output ingredients
dedusted seeds,conditioned seeds,coated seeds,dried seeds
Market info

Technical Specifications


Capacity
4-8 t/hr (wheat seeds)
Automation
Manual / PLC and Touch panel controlled system available
Cooling option
Optional air cooling unit
Adaptability
Compatible with existing rotary coating systems
Humidity and Process Variables
Customizable based on needs
Design
Compact
Air Conditioning Options
Several available
Drying Time
Variable

Operating Characteristics


Automation level
Manual / PLC
Batch vs. continuous operation
Inline Continuous
Conditioning method
Dedust and condition
Capacity range
4-8 t/hr
Cooling options
Air cooling unit

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Physical Characteristics


Adaptability
Can be placed behind existing systems
Cooling unit option
Optional air cooling unit
Control panel type
PLC and Touch panel
Conditioner capacity
4-8t/hr (wheat seeds)

Custom Options


Control panel type
Manual / PLC and Touch panel
Integration possibilities
Adaptable to existing rotary coating systems
Cooling options
Air cooling unit available
Capacity customization
4-8t/hr,adaptable depending on process needs
Drying time options
Various drying times available
Air conditioning options
Several options depending on the process
