Automatic case erector for cartonboard packaging

Streamline your packaging process with precision engineering that simplifies the transition from manual to automated systems, ensuring efficient handling of cartonboard packaging with precise flap closure and enhanced flexibility for space-constrained production lines.

Packs, Erects, Seals, and Inserts Partitions

APE Impianti’s Productive Series offers robust packaging solutions tailored for wine, beer, spirits, and food industries, seamlessly integrating into your production line for enhanced automation. The FORM 1300 case erector efficiently constructs RSC-American cartons using hot-melt glue, ensuring stability and precision. The AXIPACK 100, equipped with brushless motor-driven linear axes, excels in case and crate packing, allowing quick format changes via an operator panel. Its modular design adapts to various space constraints, offering unmatched flexibility. The INCA BS robotic case packer uses vacuum suction to gently handle labeled bottles, while the AXI INSER 100 partition inserter provides a straightforward, reliable solution for carton partitioning. Completing the lineup, the CH S11 NS and CH 1000 models automate carton flap sealing with adhesive tape or hot-melt glue, prioritizing efficiency and pack integrity. Designed for continuous, high-speed operations, these machines facilitate seamless energy efficiency and ease of integration within diverse packaging environments.

Benefits

  • Increases production efficiency by automating packaging processes, reducing manual labor and operational errors.
  • Enhances flexibility with modular designs adaptable to varying production line constraints.
  • Protects product integrity with precise material handling, preserving labels and bottle conditions.
  • Minimizes format changeover times through user-friendly operator panels, improving productivity.
  • Achieves consistent packaging quality with advanced sealing and case erecting mechanisms.

General


Applications
Food,Wine,Cartons,Spirits,Bottles,Beer
End products
Beer bottles,Packaged liquid products,Glass return bottle cases,Packaged food products,Bottled beverages,Rsc/american carton boxes,Wine bottles,Non-alcoholic beverage bottles,Labeled bottles with vacuum suction,Carton-packed beverages,Processed food packaging,Spirits bottles
Steps before
Bottle Unloading,Labeling,Capsule Application
Steps after
Carton Sealing,Palletizing,Shipping Preparation
Input ingredients
bottles,cartons,plastic crates,RSC-AMERICAN cartonboard,cardboard dividers,adhesive tape,hot-melt glue
Output ingredients
packaged bottles,sealed cartons,packed crates,closed carton boxes,automated packaging
Market info

Technical Specifications


Automation
Full automation of production processes
Speed
Up to 6,000 bottles/hour
Case Style
RSC-AMERICAN cartonboard
Gluing Method
Hot-melt glue
Motor Type
Brushless motors
Packaging Type
Case and crate
Head Type
Fully motorised head
Space Adaptability
Modular design
Robotic System
2 linear axes
Suction Head Type
Vacuum suction head
Head Control
Automated format changes
Flap Closure
Adhesive tape
Partition Insertion
Automated
Control Model
Operating logic

Operating Characteristics


Automation level
Fully automated / Modular
Changeover time
Fast format change
Batch vs. continuous operation
Inline Continuous
Cleaning method
Automatic
Energy efficiency
Brushless motors for efficiency

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Physical Characteristics


Machine footprint
Compact
Feed/Discharge Method
Automatic case insertion
Control panel type
Fully motorized with operator panel
Compact footprint
Modular Design
Discharge method
Vacuum suction head

Custom Options


Control panel type
Operator panel with automated format changes
Integration possibilities
Modular design for flexibility
Drive system
Linear axes driven by brushless motors
Handling control
Precision enhanced in "PLUS" version
