Apple, pear, and kiwi juice extraction line

Achieve high-yield juice production from apples, pears, and kiwis while retaining their natural aroma and qualities through cold extraction in an inert atmosphere, ensuring minimal oxygen incorporation for optimal flavor outcomes.

Extracts and Refines Juices from Seeded Fruits

The Temperate Climate Multifruit Extraction Line, featuring equipment like the Extractor with Beaters ARTEMIDE and the Turbo Refiner HERA, from Tropical Food Machinery specializes in processing apples, pears, and kiwis. It utilizes a cold extraction method in an inert atmosphere to ensure high yield and flavor retention. The line efficiently separates skins and seeds, integrating seamlessly into fruit juice and purée production processes. With capacities ranging from 2,000 to 15,000 kg/h, it supports continuous high-speed operations across industries like juice production and food processing. The line includes a preheater, evaporator, homogenizer, and sterilization plant, enhancing product quality and compliance with international standards. Configured for energy efficiency and robust corrosion resistance, this extraction line offers customizable options to meet specific production needs while ensuring easy cleaning and maintenance. It delivers versatility, transforming fresh produce into a wide range of products, including clear juices, concentrates, and purées for global markets.

Benefits

  • Enhances product quality by preserving flavor and nutrients through cold extraction.
  • Increases operational efficiency with continuous high-speed processing.
  • Reduces energy consumption by optimizing inert atmosphere conditions.
  • Minimizes waste by ensuring high yield and thorough separation of skins and seeds.
  • Provides versatility in product output, from clear juices to concentrated purées.

General


Applications
Concentrated juice,Jam,Fruit beverage,Fruit purée,Fruit in pieces or chunks,Tomato sauce,Fruit juice
End products
Pear chunks,Pear-flavored beverage,Kiwi purée,Kiwi slices,Ready-to-use tomato sauce,Clear apple juice,Apple juice concentrate,Kiwi juice,Apple pieces,Apple jam,Pear purée,Kiwi jam,Kiwi juice concentrate,Pear juice concentrate,Apple purée,Kiwi-flavored beverage,Pear nectar,Apple-flavored beverage,Pear jam
Steps before
Washing,Brushing,Sorting,Blanching
Steps after
Concentration,Sterilization,Aseptic Filling
Input ingredients
apples,pears,kiwis,fresh fruit
Output ingredients
pulp,refined juice,clarified juice,concentrated juice,top-quality juice
Market info
Tropical Food Machinery is known for manufacturing engineered-to-order (ETO) industrial equipment, specializing in fruit and vegetable processing machinery. They are reputed for innovation, quality, and global service in the food processing industry.

Technical Specifications


Capacity
2,000 Kg/h to 15,000 Kg/h
Juice extraction method
Cold extraction in inert atmosphere
Automation
Automatic with Extractor,Preheater,Turbo Refiner
Pre-treatment steps
Washing,brushing,sorting,blanching
Concentration method
Evaporator by forced circulation
Sterilization method
Aseptic environment sterilization
Aseptic filling options
For 220 l drums,1000 l bins or goodpaks

Operating Characteristics


Batch vs. continuous operation
Batch / Inline Continuous
Air incorporation control
Cold extraction in an inert atmosphere
Automation level
PLC-controlled
CIP/SIP
CIP 121°C / SIP 135°C
Cleaning method
Manual / CIP
Energy efficiency
0.5–2 kWh/kg moisture

Material Compatibility


Abrasion resistance
High
Biological compatibility
Food Grade
Corrosive resistance (e.g. acids)
Stainless Steel
Cleanability
CIP Ready

Product type Characteristics


Fruit type processed
Apple,Pear,Kiwi

Physical Characteristics


Machine footprint
Variable based on capacity (2,000 Kg/h to 15,000 Kg/h)
Tank size
220 L drums,1000 L bins
Feed method
Pre-treated with washing,brushing,sorting,blanching
Discharge method
Aseptic filling
Compact footprint
Design optimized for space efficiency
Control panel type
Digital/Automated

Custom Options


Control panel type
Touchscreen / HMI
Integration possibilities
SCADA / ERP
Compact footprint
Modular design
Discharge method
Gravity / vacuum
