Agitator for Ibc containers

Achieve consistent and efficient mixing of various liquid products with this agitator, ensuring precise agitation even at low fill levels and reducing wear on components with its unique slow-speed operation.

Agitates and Mixes Liquid Products Efficiently

The Tetra Pak® Agitator IBC is a specialized solution for efficient liquid processing, developed by Tetra Pak to ensure consistent and gentle agitation. Its unique design employs auto-extending mixer blades that rotate slowly, engaging a large surface area to mix liquids up to four times faster than conventional models. This agitator is particularly suitable for applications involving food concentrates, liquid aromas, juices, and dairy products, accommodating liquid viscosities below 200 cP.

Capable of batch and continuous operations, the Tetra Pak Agitator IBC integrates smoothly into various production environments, offering a hygienic, easy-to-clean construction with no bearings, minimizing contamination risk. The agitator is engineered for durability, featuring a slow blade rotation that reduces motor wear, thus extending the equipment’s operational life.

Supporting flexible operations, it provides several options such as explosion protection and frequency inverters for adaptable mixing effects, enhancing efficiency and customizing according to product types and volumes. It meets industry hygiene standards with available CIP containers for fully automated cleaning. Ideal for food and beverage manufacturers and liquid chemical producers, it addresses challenges in maintaining product integrity and consistent agitation in diverse operational conditions.

Benefits

  • Enhances mixing efficiency, achieving up to four times faster agitation for improved production speed.
  • Reduces maintenance costs due to slow blade rotation, minimizing wear on mechanical components.
  • Ensures product integrity with gentle agitation, ideal for sensitive liquids and flavors.
  • Provides flexible operation with options for explosion protection and adaptable mixing speeds.
  • Facilitates easy cleaning and minimizes contamination risk with a hygienic, contact-free design.

General


Applications
Food concentrates,Plant-based products,Liquid chemical compounds,Juices,Liquid aromas and flavours,Dairy products
End products
Almond milk,Liquid detergent,Milk,Orange juice,Vanilla extract,Fruit concentrate syrup
Steps before
Liquid ingredient preparation,Concentration,Aroma extraction,Juice collection
Steps after
Filling,Bottling,Packaging,Labelling
Input ingredients
Output ingredients
Market info
Tetra Pak is renowned for providing innovative packaging solutions, specializing in carton packaging for the food and beverage industry. It is esteemed for high-quality, sustainable, and efficient processing and packaging equipment on a global scale.

Technical Specifications


Capacity
For use with standard IBCs
Viscosity
Less than 200cP
Agitation Speed
Four times faster than conventional agitators
Material
Stainless steel chain
Explosion Protection
ATEX zone 22
CIP Capability
CIP container for four agitators
Flexibility
Frequency inverter for adapting mixing effect

Operating Characteristics


Working Mechanism
Auto-extending mixer blades
Integrated Steps
Agitation and mixing
CIP Principles
Hygienic design
Batch vs. Continuous Operation
Batch
Agitation Speed
Slow,gentle mixing
Cleaning Method
Easy-to-clean design
Automation Level
Manual operation with status indicator
Flexibility
Handles various liquid viscosities
Fill Level Independence
Agitation consistent at any fill level

Material Compatibility


Corrosive resistance (e.g. acids)
Stainless steel
Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Product type Characteristics


Liquid Viscosity
Less than 200cP
Container Size
Industry standard IBC
Container Shape
Rectangular
Product Sensitivity
Heat Sensitivity


ATEX certification
Zone 22

Physical Characteristics


Compact footprint
Designed for use with standard IBCs
Control panel type
Not specified
Discharge method
Auto-extending mixer blades

Custom Options


Integration possibilities
Frequency inverter
Explosion protection
ATEX zone 22
Storage platform integration
Four agitators
CIP container
For fully hygienic and automatic cleaning
