A loading system feeds your continuous or batch processing machine with the specified material or item in line with the flow of production. Loaders transfer the articles from one stage of preparation to the next with uniformity and accuracy.

Loading

Sulphur

To ensure the safety of operator while working between a loading platform and road or rail tankers, folding stairs and safety cages are essential to provide safe and efficient means of access.


<h2>Folding stairs and safety cages for safe operation</h2>
Kanon Folding Stairs and Safety Cages are built to latest safety standards. The spring-balanced design ensures easy operation by a single operator.

The Safety Movable Stairs (SMS) provide the possibility to access almost any side of the road or rail tanker or container. The safety cages are available at sizes of 1400 mm deep and width ranging from 1400 mm up to 12000 mm. Pneumatic or hydraulic operation is possible.

Folding stairs and safety cages

A hose or loading arm is needed when you load or unload fluids from a ship or transfer fluids between vessel and shore. If you want a safer, easier to operate and longer service life than a hose, a marine loading arm is the ideal solution.


<h2>Marine loading arms to meet liquid loading needs</h2>
Kanon Marine loading arms are manufactured in line with the latest requirements of OCIMF and major oil companies. It permits emergency release action without any spillage of product and without pollution. Kanon marine loading arms require minimal maintenance and all product seals can be replaced without scaffolding or dismantling the loading arm itself.

KANON’s single counterweight balance system enables both hydraulically and manually operated arms to be maneuvered easily and safely, saving both time and manpower.

Marine loading arm

Load or unload liquids from the top of the tanks safely and securely for trucks, railcars, small or big containers, ISO containers, drums of 220 liters, etc.


<h2>Safe, hassle-free loading from the top of the tank</h2>
KANON top loading arms come in different designs depending on the application. These can be open filling systems as they are commonly used in for a wide range of products across all industry sectors. But they can also be designed for closed filling for highly aggressive liquids associated with the chemical and petrochemical industries.

Loading arms can be executed with or without vapour return or pressure line. They can outfit with top level detection (bubble pipe sensing or electronic). A telescopic drop pipe can be integrated to prevent foaming or electrostatic build up. Adding a press down cylinder will prevent arm lifting or add a drop pipe deflector to prevent dripping.

Kanon top loading arms are provided with four swivel joints for the product line and a counterweight or multi-coil spring cylinder balance system.

Top loading arm

Bottom loading/unloading arms are designed to be connected on the side or on the rear of the tanker and sometimes for both.


<h2>Safe, hassle-free loading from the side or the rear of the tank</h2>
Kanon bottom loading arms are used both for open loop and closed loop fluid transfer. The “open loop” product transfer uses a single bottom loading arm. A combination of two bottom loading arms is used simultaneously for “closed loop” product transfer. Closed loop product transfer is necessary for low density liquids.

Kanon loading arms are equipped with five swivel joints and a multi-spring balance cylinder. The use of Kanon balance cylinders ensures that bottom loading arms can be maneuvered through all positions with minimal effort.

Bottom loading arm

Find production technology for Sulphur loading, and connect directly with leading machine manufacturers worldwide

Sulphur loading

Which sulphur loading equipment do you need?

Folding stairs and safety cages

Marine loading arm

Top loading arm

Bottom loading arm

There is currently no equipment listed with your specified properties, but we are sure we can help you. Try us!Contact us
