Troughed belt conveyor for efficient material transport

Effortlessly transport a variety of materials, from glass to municipal waste, with this robust and low-maintenance troughed belt conveyor designed for high-speed operations and seamless integration into existing processing lines.

Conveys and Transports Bulk Materials Efficiently

The BRS Troughed Belt Conveyor by Bollegraaf stands out for its robust design and efficient operation, perfectly suited for recycling companies and industrial material handling businesses. Its modular construction features a U-shaped trough supported by durable steel-plate frames, ensuring sustained performance under continuous, high-speed conditions. Driven by a drum motor, it minimizes maintenance through lifetime-lubricated bearings capable of 10,000 hours of operation.

Perfect for transporting materials like glass, cans, and recyclables, it efficiently integrates into recycling and waste management processes to produce end-products such as recycled aggregates, paper sheets, and refuse-derived fuel. With adaptable configurations, it fits seamlessly into existing layouts, managing vast material quantities across long distances. Enhanced by automated controls, the conveyor aligns with energy-efficient practices, delivering reliable material transport while enabling easy cleaning and maintenance through its accessible design. Suitable for various environments, the BRS conveyor offers customization and engineering support to meet specific project requirements.

Benefits

  • Minimizes maintenance with lifetime-lubricated bearings for up to 10,000 hours of operation.
  • Adapts to diverse installations with modular, configurable design.
  • Enhances efficiency in material processing lines by reducing labor requirements through automated operation.
  • Increases operational longevity with robust steel-plate frame construction.
  • Supports sustainable practices with its ability to handle various recyclable and waste materials efficiently.

General


Applications
Paper and cardboard waste,Waste-to-energy,Single stream waste,Construction and demolition (c,Plastic waste,Glass,Municipal solid waste (msw),Sand,Paper,D),Cans
End products
Processed municipal solid waste,Mixed recyclables,Aluminum beverage cans,Recycled cardboard boxes,Recycled paper sheets,Recycled construction aggregates,Recycled sand aggregates,Plastic pellets,Refuse-derived fuel (rdf),Glass bottles
Steps before
Material Collection,Pre-sorting,Shredding
Steps after
Screening,Ballistic Separation,Density Separation,Baling
Input ingredients
glass,cans,sand,paper
Output ingredients
transported materials
Market info
Bollegraaf is known for manufacturing advanced recycling equipment and systems. With a strong reputation for innovation and quality, they specialize in engineered-to-order solutions, optimizing waste processing efficiency and sustainability for diverse industries globally.

Technical Specifications


Bearing Diameter
80 mm
Troughing Angle
25°
Distance Between Trough Frames
1000 mm
Return Roller Spacing
Max. 2500 mm
Maintenance Interval
10,000 hours
Trough Frame Construction
Modular
Automation
Well automated production process

Operating Characteristics


Maintenance requirement
Low
Automation level
Well automated
Modular construction
Adjustable

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm
Biological compatibility
0
Cleanability
0

Physical Characteristics


Conveyor shape
Troughed U shape
Trough frame construction
Solid steel-plate frame
Trough frame configuration
Three bearing-mounted rollers
Troughing angle
25°
Roller diameter
80 mm
Rubber belt width
50 mm (on steel plate)
Support ring roller distance
Max. 2500 mm
Modular construction
Fully adjustable
Footprint adaptability
Adjustable to space requirements
Characteristic feature
Durability and low maintenance
Machine footprint
Adjustable,designed for space flexibility

Custom Options


Modular construction frame
Fully adjustable to space requirements
Customizable conveyor configuration
Can be placed in practically any situation
