Solventless cannabis extraction system for large-scale operations

Optimize your large-scale cannabis, hemp, or hops processing with an efficient system designed for precise trichome isolation and streamlined cleaning, ensuring high-quality resin concentrates without the use of solvents.

Extracts Trichomes from Fresh and Dry Biomass

The WT-2000 from Whistler Technologies is a robust solventless extraction system tailored for large-scale cannabis, hemp, and hops processing. It efficiently isolates trichomes using a specialized design capable of handling up to 160 kg of fresh frozen or 53 kg of dry biomass per run. The machine features an integrated Clean-In-Place (CIP) system that eliminates additional cleaning equipment, streamlining operations. Its stainless steel construction, using grades 316 and 304, ensures durability and compliance with food-grade and customizable cGMP or EU GMP standards. Designed for high-capacity, batch, and automated operations, the WT-2000 facilitates production of trichome isolates, live resin concentrate, and solventless cannabis oil. Customize its automation capabilities, such as spent biomass removal and automatic valve actuation, for seamless integration into your farm-scale processing line.

Benefits

  • Increases operational efficiency with high-capacity processing of up to 160 kg per run.
  • Simplifies cleaning and maintenance with an integrated CIP system, reducing downtime.
  • Ensures product safety and compliance with customizable cGMP or EU GMP standards.
  • Enhances product purity by utilizing a solventless extraction method.
  • Facilitates seamless integration and scaling within large-scale processing operations.

General


Applications
Cannabis,Hemp,Hops
End products
Hemp resin,Bubble hash,Hops extract,Trichome isolates,Solventless cannabis oil,Live resin concentrate,Cannabis resin,Kief
Steps before
Harvesting,Trimming,Grinding,Freezing
Steps after
Trichome Isolation,Post-processing,Drying,Quality Assurance
Input ingredients
cannabis,hemp,hops,fresh frozen biomass,dry biomass
Output ingredients
trichomes,fresh frozen output,dry material output
Market info
Root Sciences is known for providing high-quality extraction, distillation, and other processing equipment for the cannabis and hemp industries, offering solutions for creating purified concentrates and extracts, emphasizing efficiency and innovation.

Technical Specifications


Capacity
Up to 54 kg dry material,Up to 160 kg fresh frozen
Run Time
1-4 hours
Yield (Fresh Frozen)
2-7%
Yield (Dry Material)
10-30%
Electrical Requirement
3 phase,70-80A line fuse,480 V or 600 V
Footprint
500+ sq ft,16’+ ceiling height
Clean in Place (CIP) System
Custom design,dynamic spray balls

Operating Characteristics


Automation level
Manual / Optional automation upgrades
CIP/SIP
Built-in CIP system
Batch vs. continuous operation
Batch operation
Cleaning method
CIP / Dynamic spray balls
Energy efficiency
High IP ratings for components

Material Compatibility


Corrosive resistance (e.g. acids)
High resistance due to stainless steel 316 and 304


CGMP compliance
Customizable
EU GMP compliance
Customizable

Physical Characteristics


Machine footprint
500+ sq ft
Ceiling height
16'+
Materials
Stainless steel 316 for wetted,304 for non-wetted components
Discharge method
Optional automation for spent biomass removal

Custom Options


Compliance
Customizable cGMP or EU GMP
Automation
Optional automation upgrades for spent biomass removal and automatic valve actuation
Construction Materials
Stainless steel 316 and 304 for wetted and non-wetted components
CIP System
Custom design with dynamic spray balls
