Semi-automatic weigher for irregular products

Efficiently handle and weigh irregular products like whole fruits and meats with precision, enhancing portioning accuracy and reducing manual errors in your packaging line.

Weighs and Portions Irregular Solid Products

The Semi Automatic Combination Weigher, models FMC 10 to FMC 16, offers a versatile solution for packaging complex, irregularly shaped products like apples, carrots, salmon fillets, and chicken breasts, addressing the needs of food processing companies, fruit packagers, and ready meal manufacturers. This machine bridges the gap between manual handling and fully automatic systems by allowing manual product placement on weigh belts, followed by automatic consolidation and conveyance for optimal portioning. Operating with a maximum speed of 30 packs per minute, it ensures precision with a minimum weight accuracy of 1g and accommodates unit weights ranging from 10g to 1kg. Designed for integration into existing lines, it supports sequential processing with multihead and linear weighers, enhancing efficiency across downstream and upstream operations. Built for endurance, the weigher functions efficiently within a temperature range of 0 to 40 degrees Celsius, is powered by a 220V, 50-60Hz supply, and its stainless-steel construction ensures ease of cleaning and compliance with food safety standards. Customization and engineering support are available to tailor the system to specific operational requirements, ensuring seamless adaptation to diverse production environments.

Benefits

  • Enhances packaging efficiency by precisely weighing and portioning irregular products.
  • Minimizes operational costs with semi-automatic functions that reduce reliance on manual labor.
  • Integrates seamlessly with existing production lines for streamlined workflow.
  • Offers versatile product handling with a weight range of 10g to 1kg, accommodating diverse packaging needs.
  • Supports food safety compliance with easy-to-clean stainless steel construction.

General


Applications
Ready meals,Meat,Fish,Irregular products,Vegetables,Whole fruits
End products
Pre-packaged stir fry kit,Salmon fillets,Mixed vegetable medley,Chicken breasts,Apples,Carrots
Steps before
Sorting,Manual Placement,Pre-weighing
Steps after
Portion Delivery,Packing,Packaging
Input ingredients
whole fruits,vegetables,fish,meat,irregular products
Output ingredients
weighed portions,product combinations
Market info
The Food Machinery Company Ltd. is known for manufacturing bespoke food processing equipment, like conveyors and mixers, offering engineering expertise for industrial-scale food production, backed by a reputation for quality and tailored solutions in the UK and international markets.

Technical Specifications


Unit Weight Range
10g – 1kg
Combinational Range
10kg,12kg,14kg,16kg
Minimum Weight Accuracy
1g
Max Speed
30 ppm
Weighing Platform Size
310 mm (L) x 150 mm (W)
Net Weight
140kg,160kg,180kg,200kg
Operation Temperature
0-40 (Degrees Celsius)
Power Supply
220V,50 – 60Hz
Automation
Manual placement,system-fed

Operating Characteristics


Automation level
Manual with automatic feeding
Batch vs. continuous operation
Batch
Changeover time
Quick changeover
CIP/SIP
Manual cleaning
Cleaning method
Manual
Energy efficiency
Efficient operation with low power usage
Weighing mechanism
Manual product placement with automatic combination

Product type Characteristics


Filling purpose
Whole fruits,vegetables,fish,meat
Product type
Irregular products
Portion size
10g – 1kg unit weight

Physical Characteristics


Discharge method
Central conveyor
Weighing belt size
310 mm (L) x 150 mm (W)

Custom Options


Control panel type
Manual placement with software integration
Integration possibilities
Central conveyor system
Weighing platform size
310 mm (L) x 150 mm (W)
