Low profile slide valve for controlling powder flow

Optimize your powder and granule flow management with precision-engineered, low-profile slide valves, designed to minimize residue and contamination while providing high abrasion resistance and seamless integration into existing systems.

Intercepts and Seals Flow of Bulk Materials

The Low Profile Slide Valves VIB-VIBX from WAMGROUP are engineered for seamless material flow interception in various industries, including food processing, construction, and environmental technology. These valves feature a compact, dustproof design using WAM’s patented SINT engineering polymer, offering high abrasion resistance and minimal contamination risk. They effectively handle bulk materials like flours, granules, and powders during gravity and conveying applications, aiding in the production of end-products such as biscuits, pet food, and rubber tires. With manual, pneumatic, or electric operation options and compatibility with WAM and CEMA flanges, these valves ensure easy integration and quick fitting into existing systems. Additionally, they accommodate various configurations with interchangeable carbon or stainless steel blades, available in sizes ranging from 150 to 400mm. Compliant with ATEX and food-grade standards, they provide a reliable and safe solution for effective flow management across diverse processing environments.

Benefits

  • Enhances production efficiency with quick installation and easy integration into existing systems.
  • Minimizes contamination risk with a compact, dustproof design and abrasion-resistant seals.
  • Reduces maintenance time and costs with a friction-free, wear-compensating seal system.
  • Supports industry-specific compliance with ATEX and food-grade certifications.
  • Offers operational flexibility with manual, pneumatic, and electric actuator options.

General


Applications
Lime,Biscuits,Steel,Noodles,Grain,Fruit processing,Cosmetics,Pesticides,Industrial waste,Animal by-products,Minerals,Chocolate,Bakery products,Fly-ash,Distilled beverages,Cement,Edible oils and seeds,Convenience foods,Insecticides,Detergents,Wine,Granular materials,Glass,Spices,Varnishes,Rubber,Cocoa,Animal feed,Fish products,Pasta,Pet food,Sugar,Meat processing,Rice,Plastics,Soaps,Resins,Baby food,Salt,Paints,Vegetable processing,Fertilizers,Sand,Pharmaceuticals,Shot blasting materials,Beverages,Coffee,Flour,Gypsum,Iron,Refractory products,Powdery materials
End products
Biscuit dough,Frozen fruit,Mosquito repellent,Dog kibble,Bottled water,Dried pasta,Nitrogen fertilizers,Pre-cut vegetables,Red wine,Ground meat,Blast furnace slag,Wheat grain,Sunflower seeds,Instant soup packets,Rubber tires,Curry powder,Processed animal meal,Cocoa powder,Steel beams,Epoxy resin,Laundry soap,Canned tuna,Portland cement,Gypsum board,Baby milk formula,Vodka,Quicklime powder,Corn flour,Olive oil,Ibuprofen tablets,Granulated sugar,Acrylic paint,Pvc pellets,Cattle feed pellets,Electrostatic precipitators for fly ash,Rice bran,Ground coffee,Recycled concrete aggregate,Instant noodles,Table salt,Silica sand,Bread loaves,Facial cosmetics,Chocolate bars,Quartz sand,Shot blast grit,Gloss varnish,Glass bottles
Steps before
Silo or bin filling,Material weighing,Conveying to storage
Steps after
Packing,Loading into transport,Feeding to next process stage
Input ingredients
powders,flakes,granular materials,dry powder,granular material
Output ingredients
powders,flakes,granular materials,dry powder,granular material
Market info
WAMGROUP is known for its expertise in manufacturing bulk material handling and processing equipment, including screw conveyors, dust collectors, and valve systems, with a strong reputation for innovation, quality, and global market presence.

Technical Specifications


Material
Aluminium alloy,Carbon or Stainless Steel
Seal Type
Elastomeric seal with SINT engineering polymer composite
Mounting Orientation
Horizontal or Vertical
Size Range
150 ~ 400mm (6” ~ 16”)
Abrasion Resistance
High
Actuator Type
Manual,Pneumatic,Electric gear motor
Flange Compatibility
WAM and CEMA
Seal System
Live-loaded,dust-proof,replaceable
Flow Interception
Gravity or Conveying

Operating Characteristics


Automation level
Manual / Pneumatic / Electric gear motor
Batch vs. continuous operation
Inline Continuous
Changeover time
Quick fitting
CIP
Not specified for CIP
Cleaning method
Manual
Energy efficiency
Not specified

Material Compatibility


Abrasion resistance
High
Bacterial / Food Safety
Compliant with EC 1935/2004
Corrosion resistance
Stainless Steel Frame
Density/particle size
Varies (Powders,flakes,granular materials)
Cleanability
Easy due to low profile design

Product type Characteristics


Suitable for material types
Powdery/Granular


Food-grade compliance
Regulation (EC) No. 1935/2004

Physical Characteristics


Machine Footprint
Compact design
Material
Aluminium alloy body,carbon or stainless steel blade and frame
Seal Material
SINT engineering polymer
Discharge Method
Gravity flow
Size
150 ~ 400mm (6” ~ 16”)
Shape
Square inlet or circular open cross section

Custom Options


Blade Material
Carbon or Stainless Steel
Frame Material
Carbon or Stainless Steel
Seal Material
SINT Engineering Polymer
Mounting Orientation
Horizontal or Vertical
Size Range
150 ~ 400mm (6” ~ 16”)
Actuator Type
Manual,Pneumatic,Electric Gear Motor
Flange Compatibility
WAM and CEMA
Dust-proof Design
Friction-Free
ATEX Version
Available
Food-Grade Version
Regulation (EC) 1935/2004 Compliant
