Horizontal plate filtration for beer brewing

Enhance your brewing process with a D.E. filter that ensures high-clarity beer and efficient filtration, while minimizing contamination risks and optimizing flow management. Perfect for producing consistent craft and specialty beers.

Filters and Clarifies Beer

The Horizontal Plate D.E. Filter for Beer by Easybräu-Velo, from TMCI Padovan, is engineered for breweries requiring precise and efficient beer clarification. This filter features plain, indeformable stainless steel AISI 304 plates and AISI 316L filtering cloth, enhancing drainage flow and cleanability. Uniquely designed without a conventional drainage grid, it minimizes contamination risks. The filter employs hydraulic coupling for motorized plate rotation and an innovative inlet flow distributor to prevent vortex formation. Ideal for filtering various beers, from lagers to craft brews, it operates continuously and at high speed, integrating seamlessly into existing production lines. The Greenfilter is PLC-compatible and facilitates easy cleaning with CIP systems, offering robust performance and reduced downtime.

Benefits

  • Enhances beer clarity and quality with efficient sediment removal.
  • Minimizes contamination risk by eliminating conventional drainage grids.
  • Reduces maintenance time with easy-clean, stainless steel construction.
  • Operates at high speed for seamless integration into continuous production lines.
  • Prevents flow disruptions with innovative inlet flow design.

General


Applications
Beverage processing,Brewing,Beer
End products
Craft beer,Ipa beer,Lager beer,Microbrewery beer,Non-alcoholic beer,Ale beer,Stout beer,Pilsner beer,Wheat beer
Steps before
Malt transport and milling,Brewhouses,Fermentation,Maturation
Steps after
Filtration and clarification,Blending and carbonation,Yeast recovery and propagation
Input ingredients
beer,liquid for filtration
Output ingredients
filtered beer,clarified liquid
Market info
Easybrau-Velo (Omnia Technologies) is known for manufacturing and supplying custom-engineered brewing and beverage processing equipment, offering tailored solutions to fit specific needs, while maintaining high quality and innovation standards in the industry.

Technical Specifications


Filtration method
Horizontal plate D.E. filter
Filtration mesh size
65 micron
Filtration material
Stainless steel AISI 316L
Frame material
Stainless steel AISI 304
Automation
Hydraulic coupling
Inlet flow distributor
Prevents vortexes and abnormal flows

Operating Characteristics


Working Mechanism
Horizontal plates filtration
Automation level
Hydraulic Coupling for Motorization
Drainage flow
Elevated drainage flow
Cleaning method
Accurate cleaning during washing phase
Vortex control
Special inlet flow distributor
Batch vs. continuous operation
Batch / Inline Continuous

Material Compatibility


Abrasion resistance
Yes
Biological compatibility
Yes
Cleanability
Stainless Steel
Corrosive resistance (e.g. acids)
Yes
Density/particle size
65 micron mesh

Physical Characteristics


Filtration Plates Material
Stainless Steel AISI 304
Filtration Cloth Material
Stainless Steel AISI 316L
Mesh Size
65 micron
Drainage Feature
No drainage grid
Rotation Motorization
Hydraulic coupling
Inlet Flow Distribution
Special distributor to avoid vortexes

Custom Options


Motorization Type
Hydraulic coupling
Filtration Plate Material
Stainless steel AISI 304
Filtering Cloth Material
Stainless steel AISI 316L,65 micron mesh
Inlet Flow Distributor
Special design to avoid vortexes
