Energy efficient wort boiling system for breweries

Maximize energy efficiency and wort quality with this boiling system that optimizes two-phase boiling processes, ensuring consistent thermal conversion and evaporation for varied beer recipes.

Optimizes Wort Boiling and Evaporation Processes

The GEA JETSTARĀ® Wort Boiling System is an innovative solution designed for breweries and beverage manufacturers focused on efficient wort processing. This system employs a two-phase boiling approach using an internal boiler for natural circulation, eliminating the need for additional pumps. In the conversion stage, it reduces thermal stress and enhances circulation homogeneity, while the two-level wort spreader during evaporation ensures intensive vaporization. Applications span a wide range of beer types, including IPAs, stouts, and specialty beers. The system integrates seamlessly into existing brewing setups or new installations, utilizing stationary operating conditions to maintain low TBI values and improve hop yields. It supports continuous, automated operation with PLC compatibility, improving energy efficiency by working well with any energy storage system. The hygienic design simplifies cleaning and maintenance, and the system is adaptable for varied recipe formulations, offering technological flexibility to brew diverse beer profiles.

Benefits

  • Enhances energy efficiency while reducing operational costs through natural circulation boiling.
  • Improves beer quality with optimal thermal conversion and low thermal stress.
  • Increases production flexibility, supporting diverse beer recipes, from lagers to specialty brews.
  • Simplifies integration and upgrades, easily retrofitting into existing brew houses.
  • Minimizes cleaning requirements, maintaining hygienic operations with reduced intervention.

General


Applications
Wort treatment,Beverages,Brewing,Beer
End products
Craft beer,Pilsner,Ipa beer,Lager,Specialty beers,Stout,Wheat beer,Seasonal beers,Ale
Steps before
Milling,Lautering
Steps after
Cooling,Fermentation
Input ingredients
water,malted barley,hops
Output ingredients
wort,evaporated water,boiled wort
Market info
GEA is known for its expertise in engineering innovative and sustainable equipment and solutions, focusing on sectors such as food, beverages, pharmaceuticals, and energy, with a reputation for quality, efficiency, and advanced technological applications in industrial processing.

Technical Specifications


Boiling Process
Two-phase boiling
Heating Method
Natural circulation evaporator
Circulation Method
Natural circulation
Automation
Intelligent Wort Management (IWM) software compatible
Evaporation Method
Two-level wort spreader
Retrofitting Capability
Easy to retrofit to existing plants
Energy Efficiency
Works with any type of energy storage system

Operating Characteristics


Working mechanism
Two-phase boiling
Integrated steps
Homogeneous circulation and intensive evaporation
Batch vs. continuous operation
Batch operation
Automation level
Intelligent Wort Management (IWM) software compatible
Cleaning method
Hygienic design facilitates cleaning
Energy efficiency
Energy efficient with any type of energy storage system
Changeover time
Easy to retrofit into existing wort kettles

Physical Characteristics


Machine footprint
Compact design
Kettle shape
Round
Feed method
Internal circulation
Discharge method
Gravity-based
Customization potential
Retrofit-friendly

Custom Options


Integration possibilities
Retrofit-compatible
HMI type
Intelligent Wort Management (IWM) software compatible
Technological flexibility
Varied recipe design for special beer types
