Empty bottle sorting system

Efficiently remove unstable, misshapen, and contaminated empty bottles before they disrupt your production line, ensuring a seamless cleaning process and maximizing your line efficiency.

Sorts and Rejects Defective Empty Bottles

The HEUFT SPECTRUM II SX is a highly automated empty bottle sorting system designed for beverage, food, and pharmaceutical producers facing the challenge of managing returnable containers. This equipment efficiently detects and rejects non-brand, misshapen, sealed, and contaminated bottles before they reach washing or filling stages, thus preventing line stoppages and preserving product integrity. It accomplishes this through advanced imaging, ultrasonic, and optical sensor technologies linked to the HEUFT SPECTRUM II central control unit, seamlessly integrated into production lines with compact designs suited for space-constrained environments. Capable of processing up to 72,000 bottles per hour, the system supports dynamic production demands while minimizing manual intervention via automated brand and format adaptation. Enhanced by real-time image processing with artificial intelligence, the system effectively differentiates between acceptable and faulty bottles, reducing false rejections and enhancing throughput efficiency. Optional remote connectivity ensures quick diagnostics and data acquisition for sustained operational effectiveness.

Benefits

  • Enhances production efficiency by preventing bottlenecks and downtime.
  • Ensures consistent product quality by removing contaminated and misshapen bottles.
  • Reduces labor requirements with automated bottle sorting and rejection.
  • Supports high-speed operations, processing up to 72,000 bottles per hour.
  • Facilitates quick format changes, accommodating various bottle types seamlessly.

General


Applications
Beverages,Pharmaceutical containers,Food containers,Returnable bottles,Empty bottles
End products
Steps before
Unpacking,Infeed Check
Steps after
Washing,Inspection,Filling,Labeling,Packing
Input ingredients
unstable empty bottles,non-brand bottles,misshapen bottles,contaminated bottles,sealed bottles,bottles with residual liquid,bottles with remnants or contamination,distorted bottles,oversized bottles
Output ingredients
suitable stable bottles,clean empty bottles,brand-matched bottles,non-contaminated bottles,bottles without closures,bottles with no residual liquid,correctly shaped and sized bottles
Market info
HEUFT is known for its expertise in inline quality inspection systems and automation solutions for the food, beverage, and pharmaceutical industries, with a reputation for innovation and reliability in ensuring product safety and integrity.

Technical Specifications


Speed
Up to 72,000 empty bottles per hour
Detection Type
Ultrasonic,Optical Sensors,Camera
Automation Level
Highly automated
Inspection System
HEUFT SPECTRUM II with HEUFT preWash II module
Camera Technology
Six high-performance cameras
User Interface
HEUFT NaVi self-explanatory user guidance
Network Technology
Gigabit Ethernet and TCP/IP
Space Requirement
Compact,space-saving integration
Residual Liquid Detection
IR fill level detection
Closure Detection
Sensor-based
Real-time Processing
HEUFT reflexx A.I. with machine learning

Operating Characteristics


Automation level
Highly Automated
Batch vs. continuous operation
Inline Continuous
Changeover time
Automatic and quick brand changes
Cleaning method
Not applicable as it is a sorting system
Energy efficiency
High
Capacity
Up to 72,000 bottles per hour

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Product type Characteristics


Bottle material
Glass/other types (must be detectable)
Bottle contamination
Lack of contamination for cleaning

Physical Characteristics


Machine Footprint
Compact stand-alone system
Integration Type
Space-saving integration
Casing Type
Space-saving casing beside central unit
Lighting and Camera Technologies
Safely encased lighting and camera technologies
Control Panel Type
Central HEUFTSPECTRUMII control unit
Performance Range
Up to 72,000 empty bottles per hour

Custom Options


Control panel type
HEUFTNaVi user guidance with audiovisual step-by-step assistance
Integration possibilities
Seamless integration into existing beverage filling lines,network-based for remote maintenance and data acquisition
Automatic adjustment
Automatic detection unit adjustments during brand and format changes
Real-time image processing
HEUFTreflexxA.I with deep learning capabilities
Compact construction
Space-saving design for confined space integration
