Dual head labeler for top and bottom label applications
Ensure precise and wrinkle-free labeling on containers and packaging of varying materials by utilizing a dual-head system for simultaneous top and bottom label application.
Applies Top and Bottom Labels Accurately
The APS-236 from Accutek is a dual head labeler designed for precise top and bottom label applications across various container types, including plastic, metal, fiber, and glass. This equipment features electronically controlled placement sensors for accurate labeling and a stepper motor drive with synchronized speed adjustments for continuous operation. Especially suitable for the food, beverage, pharmaceuticals, and cosmetics industries, it accommodates labels up to 6 inches tall and 11 inches long, ensuring flexibility in product presentation. The heavy-duty construction supports rigorous three-shift operations, while the easy-to-use touch screen system with job memory streamlines setup and changeovers. Built with a sanitary stainless steel frame, the APS-236 also offers options for hot stamp date/lot coding and various material sensors to suit your specific application needs.
Benefits
- Enhances labeling accuracy, minimizing rework and waste with placement sensors.
- Improves productivity with synchronized speed adjustments for consistent operation.
- Simplifies changeovers and setup time with touch screen control and job memory features.
- Ensures durability in demanding environments due to robust stainless steel construction.
- Versatile application for diverse industries, accommodating various container types and label sizes.
- Applications
- Tubs,Trays,Glass containers,Plastic containers,Metal containers,Fiber containers
- End products
- Ice cream tubs,Beverage bottles,Glass food jars,Ready-meal trays,Medicine fiberboard drums,Cosmetic jars
- Steps before
- Container Unscrambling,Container Filling,Container Capping
- Steps after
- Packing,Inspection,Shrink Wrapping
- Input ingredients
- plastic containers,metal containers,fiber containers,glass containers,trays,tubs
- Output ingredients
- labeled containers,labeled trays,labeled tubs
- Market info
- Accutek is known for manufacturing high-quality engineered-to-order (ETO) equipment, specializing in custom automation and packaging solutions. They are reputed for their innovation, reliability, and ability to meet complex industrial needs.
- Label Head Can Dispense Label Size
- 6” (15 cm) Tall
- Label Length
- 0.5”–11” (1.25–28 cm)
- Maximum Roll Diameter
- 13.5″
- Height
- 60” (152.4 cm)
- Length
- 68” (172.7 cm)
- Depth
- 40” (101.6 cm)
- Weight
- Approx. ~425 lbs. (193 kg)
- Electrical
- 110 VAC,60 Hz,Single Phase (220VAC Optional)
- Automation
- In Line Automatic Applications or Semi Automatic Use
- Touch Screen Control System with Job Memory
- Yes
- Speed Selections
- 8 Different Speed Selections
- Dual Head Labeler
- Designed for Top and Bottom Labeling
- Automation level
- Manual / PLC / Touch Screen Control System
- Batch vs. continuous operation
- Inline Continuous
- Changeover time
- Auto Label Learn™ and Job Save
- Cleaning method
- Manual
- Dual Label Heads
- Top and Bottom Labeling
- Speed Adjust
- Synchronized Auto Speed Adjust with 8 Different Selections
- Power Assisted Web Take Up
- Manages Label Roll Waste
- Wrinkle Free Application
- Full Tamp Station
- Material Type
- Plastic
- Material Type
- Metal
- Material Type
- Fiber
- Material Type
- Glass
- Container type
- Plastic,Metal,Fiber,Glass
- Label size
- Up to 6 inches tall,11 inches long
- Conveyor type
- Synchronized with 8 Speed Selections
- Labeling mode
- Top and Bottom Labeling
- Container shapes
- Trays,Tubs
- Machine Footprint
- Height
- Weight
- Approx. ~425 lbs. (193 kg)
- Label Length
- 0.5”-11” (1.25-28 cm)
- Label Height
- 0.5” – 6” (1.9-15.25 cm)
- Maximum Roll Diameter
- 13.5”
- Control Panel Type
- Touch Screen Control System
- Frame Construction
- Sanitary Stainless Steel
- Control panel type
- Touch Screen Control System
- Integration possibilities
- Synchronized Conveyor/Label Head
- Automation level
- In Line Automatic / Semi Automatic Use
- Maximum roll diameter
- 13.5″
- Label Head Size
- 6” Tall Labels
- Label Learn,Job Save
- Yes
- Speed Selections
- 8 Different Speed Selections
- Frame Material
- Sanitary Stainless Steel
- Sensor Type
- Electronically Controlled Placement Sensor
- Options
- Hot Stamp Date/Lot Coder,Alpha Numeric Starter Kit,Pneumatic Separator,Clear Label Sensor,Star Wheel Separator,Conical Label Heads for Curved Packages,Casters
