Disc filler for dry powder inhalers

Optimize your dry powder inhaler production with precision micro-dosing for diverse powder properties, ensuring efficient filling of DPI discs with minimal waste and enhanced flow control.

Fills and Assembles DPI Discs

The Disc Filler from Harro Höfliger is a semi-automatic solution designed for precision filling of dry powder inhaler (DPI) discs. This equipment ensures simultaneous filling of multiple disc cavities, using a membrane filling method that prevents powder abrasion and clogging. It supports applications in pharmaceutical and medical device manufacturing, specifically for products like asthma medication discs and microfluidic cartridges for lab automation. The Disc Filler can integrate seamlessly into automated production lines, enhancing throughput with additional filling heads. It allows easy format changes via two interchangeable parts, making it versatile for varying cavity geometries and arrangements. The system supports different micro-dosing methods, including tamping pin and dosator, suitable for diverse powder properties. Compliant with industry standards, the equipment offers gentle powder handling and high accuracy in dosing, vital for maintaining product integrity.

Benefits

  • Increases production efficiency by simultaneously filling multiple disc cavities.
  • Reduces changeover time with quick format and product changes.
  • Ensures precise micro-dosing for consistent product quality.
  • Minimizes waste and contamination risk through gentle powder handling.
  • Easily integrates into existing production lines, boosting output capabilities.

General


Applications
Medical devices,Lab automation,Diagnostic products,Dry powder inhalers,Pharmaceutical devices
End products
Copd treatment powder discs,Inhalation drug powder carriers,Asthma inhalation medication discs,Diagnostic reagent discs,Dpi discs for dry powder inhalers,Microfluidic discs for lab automation
Steps before
Steps after
Assembly,Packaging
Input ingredients
dry powder,empty inhaler disc
Output ingredients
DPI discs,filled inhaler disc
Market info
Harro Hoefliger is known for its expertise in manufacturing custom, engineered-to-order packaging and production equipment, particularly for the pharmaceutical, healthcare, consumer goods, and chemical industries, with a reputation for precision, innovation, and quality engineering solutions.

Technical Specifications


Automation
Semi-automatic
Filling capacity
Disc cavities
Filling method
Membrane filling
Filling accuracy
Precise micro-dosing
Format change
Quick format change
Powder handling
Gentle to prevent abrasion and clogging
Cavity compatibility
Varying geometries and arrangements

Operating Characteristics


Working mechanism
Membrane filling method
Automation level
Integrated into automated machines
Batch vs. continuous operation
Batch
Changeover time
Quick format change
Cleaning method
Not specified

Material Compatibility


Abrasion resistance
Yes
Biological compatibility
Yes
Cleanability
Yes
Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Physical Characteristics


Discharge method
Swivel dosing unit
Compact footprint
Yes

Custom Options


Integration possibilities
Automated machines integration
Format changeover
Quick format change by exchanging two parts
Filling heads
Additional filling heads can increase output
