Continuous impact vibrators for bulk solids discharging
Handling materials like clay, sludge, or manure often leads to challenges like incrustations or bridging within silos or bins. These issues affect the efficiency of discharging and loading bulk solids.
Solve material flow problems with continuous impact
The P-Series Continuous Impact Vibrators from WAMGROUP are designed to address common issues in bulk solids handling, such as material sticking to walls, bridging, and rat-holing. The equipment generates a shockwave through the continuous impact of an internal piston on a metallic base mount, ensuring efficient material flow. The vibrators operate at a pressure range of 2 to 6 bar (29 ~ 87 PSI) and are suitable for use with wet or electrostatic powders. They can handle high temperatures up to 200°C (390°F) and are made from robust powder-coated aluminium and grey cast iron. Available in three sizes, these vibrators are easy to install on a base mounting plate, which needs to be welded onto the silo or bin wall. For safety during installation and maintenance, it is recommended to use a safety chain. Accessories like a noise reduction plate and ATEX compliance kit are also available.
Benefits
- Robust and compact design
- Ensures continuous material flow
- Handles high temperatures up to 200°C (390°F)
- Easy to install
- Suitable for explosive environments (ATEX-compliant)
