Continuous de-oiling centrifuge for metalworking industry

Efficiently de-oil and process diverse metalworking residues with a solution designed to handle continuous heavy-duty operations, optimizing your material recovery and reducing waste.

De-oils and Separates Metalworking Waste

The KSE Series from CEPA is a robust lineup of continuous de-oiling centrifuges, ideal for managing metalworking waste. These centrifuges utilize a hydraulically driven lifting base for consistent de-oiling of metal chips, grinding sludge, and shredder materials. With capacities ranging from 950 to 5,500 liters per hour, the KSE series is engineered for high throughput operations in metalworking, chemical, and pharmaceutical industries. Its continuous operation and automatic discharge mechanism ensure seamless integration into existing production lines. The equipment is constructed with precision to handle varying densities of metal waste, using centrifugal force to effectively separate oils and emulsions. Available with different drum diameters, the KSE centrifuges are tailored to meet specific production requirements, offering energy-efficient solutions with potential integration of PLC control systems for enhanced process management.

Benefits

  • Increases efficiency by consistently de-oiling up to 5,500 liters per hour.
  • Minimizes waste and enhances recyclability through effective separation of metalwork residues.
  • Reduces operational costs with continuous, automated discharge of materials.
  • Seamlessly integrates into existing production lines, enhancing workflow productivity.
  • Offers flexibility in handling various metalworking waste forms, from chips to sludge.

General


Applications
Grinding sludge,Metal chips,Oil sludge,Shredder material,Emulsion sludge,Metalworking industry,Cast chips
End products
De-oiled metal chips,Filtered emulsion residues,Dry cast iron chips,Refined metalworking waste,Processed shredder residue,Recycled metal fines,Dehydrated grinding sludge
Steps before
Shredding,Grinding,Chip Collection
Steps after
Material Collection,Chip Disposal,Oil Recovery,Recycling
Input ingredients
metal chips,grinding sludge,shredder material,oil-sludge,cast-chips,emulsion-sludge
Output ingredients
dry chips,de-oiled chips
Market info

Technical Specifications


Throughput (chips)
950-5500 l/h
Throughput (oil-sludge and cast-chips)
660-3500 l/h
Throughput (emulsion-sludge)
430-540 l/h
Max Speed
1000-1550 min-1
RCF (G-value)
410-530
Drum Diameter
400-750 mm
Automation
Automatic
Operation Mode
Continuous

Operating Characteristics


Working mechanism
Hydraulic lifting base
Continuous operation
Yes,continuous feed
Automation level
Automatic
Discharge method
Upwards over slotted-hole screen

Material Compatibility


Density/particle size
Variable - handles metal chips,grinding sludge

Product type Characteristics


Material Processed
Metal chips,grinding sludge,shredder material

Physical Characteristics


Drum diameter
400 mm,500 mm,600 mm,750 mm
Discharge method
Hydraulically driven lifting base

Custom Options


Control panel type
PLC / HMI
Integration possibilities
Existing conveyor system
Lifting intervals
Adjustable
Screen type
Slotted-hole screen
Hydraulic system
Hydraulically driven lifting base
