Cell culture hood with Co2 incubator
Achieve precise environmental control for sensitive cell studies with an integrated laminar flow hood and CO2 incubation, offering reliable sterility and optimal conditions for reproducible experimental results in applications such as cell and gene therapy or regenerative medicine.
Maintains Sterile, Controlled Cell Culture Environment
The Incubator FlowBox from Sartorius offers a unique solution for maintaining optimal conditions in biopharmaceutical and cell therapy labs. Combining a laminar flow hood with precise CO2 and environmental control, it ensures sterile, stable environments for critical cell culture processes. Ideal for producing monoclonal antibodies, mRNA vaccines, and CAR-T cell therapies, this equipment supports a wide range of applications including gene therapy and regenerative medicine. With its user-friendly control panel, adjustable configurations, and automated operations, the Incubator FlowBox integrates seamlessly into laboratory workflows, offering energy-efficient and customizable options to meet specific research demands. Constructed with durable materials, it upholds stringent compliance standards and supports sterile processing with HEPA filtration and UV sterilization. Designed for efficiency, it features an easy-to-maintain setup with full access for cleaning and configuration, ensuring consistency and reliability in all experiments.
Benefits
- Enhances cell viability and quality by maintaining precise environmental conditions.
- Saves labor costs with automated control of temperature, CO2, and humidity.
- Supports flexible research needs with customizable configuration options.
- Ensures consistent results through HEPA filtration and UV-C sterilization.
- Facilitates easy integration with existing lab setups, improving efficiency.
- Applications
- Cell line development,Vaccines,Monoclonal antibodies,Mrna production,Biosimilars,Regenerative medicine,Advanced cell systems,Bioconjugation,Biopharmaceuticals,Cell and gene therapy
- End products
- Conjugated antibody-drug complexes,Regenerative tissue scaffolds,Car-t cell therapies,Therapeutic protein formulations,Gene therapy vectors,Stem cell culture systems,Mrna-based vaccines,Monoclonal antibody therapeutics,Adenoviral and lentiviral vectors,Biosimilar drugs
- Steps before
- Cell Preparation,Culture Medium Preparation,Equipment Cleaning,Setup Environment,Cell Seeding
- Steps after
- Cell Analysis,Data Collection,Experiment Monitoring,Sterilization,Equipment Maintenance
- Input ingredients
- live cells,temperature,CO2,humidity,cell culture media,laboratory equipment
- Output ingredients
- optimal cell viability,experimental results,imaging data,sterile conditions
- Market info
- Sartorius AG is renowned for manufacturing high-precision laboratory and bioprocess equipment. They specialize in filtration, fermentation, and cell cultivation systems, known for their innovation and reliability in the pharmaceutical and biotech industries.
- Laminar Flow
- Continuous vertical laminar air flow
- Filters
- HEPA H14 (0.1 - 0.3 µm)
- UV Sterilization
- UV-C illumination lamps (4 x 15 W)
- Operated from the control panel
- Temperature Control
- Adjustable up to 40 °C
- CO2 Level and Stability
- 5 % +/- 0.2 % (constant level permanently regulated)
- Humidity Level Control
- Up to 65 %
- Purified Water Tank
- 10 l (included)
- User Protection
- Automated security locks on all doors
- Exhaust System
- Possible connection to room exhaust (max. exhaust air volume
- Internal Dimensions
- W 99 cm x D 62 cm x H 63 cm (W 39.0'' x D 24.4'' x H 24.8'')
- External Dimensions
- W 110 cm x D 85 cm x H 160 cm (W 43.3'' x D 33.5'' x H 63.0'')
- Height with Base Stand
- H 230 cm (H 90.6'')
- Weight
- 175 kg (386 lb)
- With CellCelector Flex
- 225 kg (503 lb)
- Power
- 115/230 V ~
- 60/50 Hz
- 10A
- Max. 2,300 W (without other equipment)
- Illumination
- LED 42 W
- Switched from the control panel
- Base Stand Features
- Includes water tank,PC workstation,and other modules,on wheels
- Environmental Requirements
- Temperature
- Relative humidity
- 30 - 85 % (not condensing)
- Air pressure
- 75 - 106 kPa
- Automation level
- Manual / PLC / SCADA
- Batch vs. continuous operation
- Batch / Inline Continuous
- CIP/SIP
- CIP 121°C / SIP 135°C
- Cleaning method
- CIP / Manual
- Energy efficiency
- 0.5–2 kWh/kg moisture
- Biological compatibility
- Suitable for sensitive cell studies
- Abrasion resistance
- Not applicable
- Corrosive resistance (e.g. acids)
- Not applicable
- Cleanability
- Easy to sterilize with UV-C lamps
- ISO Certification
- ISO 9001
- Machine footprint
- External dimensions
- Internal space dimensions
- W 99 cm x D 62 cm x H 63 cm
- Base stand height
- H 230 cm
- Weight
- 175 kg (standard)
- 225 kg (with CellCelector Flex)
- Discharge method
- Possible connection to room exhaust
- Control panel type
- User-friendly interface for full control over features
- Mobility
- Mounted on wheels for easy movement
- Control panel type
- User-friendly,full control
- Internal dimensions
- W 99 cm x D 62 cm x H 63 cm
- External dimensions
- W 110 cm x D 85 cm x H 160 cm
- Door access
- Sliding doors,customizable layouts
- Mobility
- Mounted on wheels
- Automation integration
- Adaptable to automation systems
- Hypoxia feature
- Available
- Glove modules
- Additional protection and accessibility
