Step screens for fine wastewater screening

Enhance your wastewater treatment with step screens that efficiently separate fine particles and reduce maintenance through self-cleaning mechanisms.

Screens and Separates Fine Particles in Wastewater

The Step Screens VTR from WAMGROUP offers a robust solution for fine screening in both municipal and industrial wastewater treatment applications. Featuring a self-cleaning design with alternating mobile and fixed lamellae, this equipment efficiently lifts and segregates non-biodegradable solids and fine particles from wastewater streams. Ideal for diverse sectors ranging from beverage processing to plastics recycling, these screens ensure enhanced clarity and contamination reduction in effluents, yielding treated water suitable for environmental discharge or further processing. The equipment operates continuously in-channel, ensuring integration ease and improved water management within the production line. With capacities accommodating widths up to 1,800 mm and discharge heights from 1,400 to 3,500 mm, the VTR Step Screens are adaptable for varying facility needs. Constructed in 304L or 316L stainless steel and customizable for specific voltages and motor protection levels, these screens also offer options for different screen types and sizes, meeting diverse operational requirements.

Benefits

  • Enhances water quality by effectively capturing fine solids and inorganic particles.
  • Reduces maintenance costs through its self-cleaning screen design.
  • Optimizes process efficiency with continuous, automated operation.
  • Adapts to varying facility needs with customizable sizes and configurations.
  • Minimizes environmental impact by ensuring high capture efficiency of contaminants.

General


Applications
Fruit processing wastewater,Plastics recycling industry wastewater,Tanneries,Industrial wastewater,Catering wastewater,Industrial solid waste handling,Clean water treatment,Animal by-products handling,Starch by-products processing,Pulp processing,Food processing wastewater,Paper processing,Beverage industry wastewater,Dyeing works,Vegetable processing wastewater,Municipal wastewater
End products
Leather tanning residues,Dye effluent clarifications,Recycled plastics rinse water,Processed industrial sludge,De-inked pulp water,Potable water,Treated municipal wastewater,Processed food and catering wastewater,Starch derivatives,Refined paper effluent,Clarified beverage processing effluents,Fruit juice residues,Vegetable wash water,Processed animal waste by-products,Treated industrial effluent
Steps before
Preliminary Screening,Coarse Screening,Initial Filtration
Steps after
Sludge Treatment,Inorganic Particle Removal,Effluent Discharge,Further Filtration
Input ingredients
wastewater,non-biodegradable solids,floating substances,inorganic substances,industrial waste water,municipal waste water
Output ingredients
screened wastewater,captured fine solids,inorganic particles,floating particles
Market info
WAMGROUP is known for its expertise in manufacturing bulk material handling and processing equipment, including screw conveyors, dust collectors, and valve systems, with a strong reputation for innovation, quality, and global market presence.

Technical Specifications


Spacing
3 or 6 mm
Incline angle
55 degrees
Width
Up to 1,800 mm
Discharge height
1,400 to 3,500 mm
Material
304 L / 316 L SS

Operating Characteristics


Working mechanism
In-channel installation
Automation level
Automated cycle
Self-cleaning
Mobile lamellae
Screen step cycle
Triggered by water level
Batch vs. continuous operation
Continuous flow
Incline angle
55 degrees
Screen spacing
3 and 6 mm
Discharge height
1,400 to 3,500 mm
Energy efficiency
Low maintenance costs

Material Compatibility


Abrasion resistance
Yes
Biological compatibility
Non-biodegradable solids
Cleanability
Self-cleaning due to mobile lamellae
Corrosive resistance
304 L / 316 L SS
Density/particle size
Inorganic particles retained

Product type Characteristics


Installation Type
In-channel
Fine Screening
Yes
Screening material
Non-biodegradable,inorganic

Physical Characteristics


Screen width
Up to 1,800 mm
Discharge height
1,400 to 3,500 mm
Spacing
3 or 6 mm
Incline angle
55 degrees
Material
304 L / 316 L SS

Custom Options


Control Panel Type
Available
Screen Types
Alternative types available
