Miniature sensor for pressure and temperature monitoring
In industrial applications, accurate monitoring of pressure and temperature is crucial, especially in systems where precise dispensing of materials is required. Challenges include maintaining exacting standards in diverse environmental conditions while minimizing material loss.
Monitor pressure and temperature in small dimensions
The flowplus-SPT M6 by Visco Tec is a miniature sensor designed for accurate pressure and temperature monitoring. It features a chemical-resistant FFKM pressure membrane and a sensor body only 15.3 mm long, with an M6 thread as the process connection. This sensor measures pressures up to 40 bar and operates within a temperature range of 5 to 50°C. It seamlessly integrates into Visco Tec dispensing systems and other applications, minimizing material loss due to its compact design. The sensor converts recorded data into an analog voltage signal for easy integration into control systems such as PLCs. With a low measurement tolerance of only 2%, it ensures high measurement accuracy. The dust- and splash-proof design, along with the stainless steel body, offers durability in industrial environments. Additional features include easy integration, reduced maintenance costs due to the robust FFKM membrane, and smooth coupling with Visco Tec controllers via a 4-pole M8 standard connection.
Benefits
- High measurement accuracy with low tolerance
- Compact design for minimal material loss
- Easy integration with control systems
- Robust construction reduces maintenance costs
- Durable in industrial environments with IP54 protection
