Interlayer sheet dispenser for palletizing

Enhance your palletizing efficiency by integrating a compact interlayer sheet dispenser, ensuring precise operation with customizable sheet formats and seamless reel changes, optimizing space and production line continuity.

Dispenses Sheets and Palletizes Products Efficiently

The Rotor from OCME innovatively combines sheet dispensing and palletizing in one compact solution, tailored for industries such as beverage, food, and personal care. It operates by cutting and distributing intermediate sheets with precision, enhancing reliability and speed by up to 25%. This machine is best integrated into automated processes, supporting a range of solid product types from soft drink packaging to industrial lubricant barrels. Capable of handling up to eight sheets per minute with space-saving logistics, it accommodates reels up to 1200 mm wide. The efficient sheet dispensing process minimizes production costs and space, reducing reliance on corrugated materials by up to 90%. Featuring an accessible reel-loading outside the safety zone, the Rotor ensures continuous operation without halting the palletizer. Available with a PLC S7 1200 control system, it offers intuitive operation and seamless integration into existing lines.

Benefits

  • Increases productivity by up to 25% with fixed pick-up height.
  • Minimizes production space by up to 90% using efficient sheet formats.
  • Ensures safety with reel loading outside the operational zone.
  • Reduces material costs by maximizing sheet dispensing reliability.
  • Seamlessly integrates into automated high-speed production lines.

General


Applications
Food,Personal care,Beverage,Tissue,Lubricants,Paper,Corrugated,Home
End products
Industrial lubricant barrels,Shampoos,Toilet paper rolls,Paper towels,Milk bottles,Motor oil containers,Ready-to-eat meals,Carbonated soft drinks,Corrugated cardboard boxes,Liquid soaps,Fruit juices,Canned vegetables
Steps before
Reel Loading,Material Setup,Sheet Measurement
Steps after
Palletizing,Logistic Optimization,Stretch Wrapping
Input ingredients
intermediate sheets,reel,sheet formats,pallet
Output ingredients
cut sheets,palletized loads,interlayer sheets
Market info
OCME, part of Aetna Group Italy, is renowned for manufacturing innovative, high-quality packaging and material handling solutions, including filling, palletizing, and conveying systems, with a strong reputation for reliability and technological advancement in industrial sectors.

Technical Specifications


Sheet Pick-up Reliability
One sheet to pick-up
Pick-up Height
Fixed,up to 25% speed increase
Sheet Format Flexibility
Multiple formats from one reel
Space Saving
Up to 90% less space compared to corrugated sheets
Reel Loading Safety
Outside safety zone
Reel Width
800 mm or 1200 mm
Maximum Reel Diameter
1000 mm
Core Diameter
100 mm
Positioning Precision
± 15 mm
Speed
Up to 8 sheets/min
Automation
PLC S7 1200
Display
Proface 3.5 color
Installed Power
1 kW
Voltage
400 V,50 Hz,three-phase

Operating Characteristics


Automation level
PLC-controlled
Changeover time
Quick changeover design
CIP/SIP
Manual/Automated Cleaning
Energy efficiency
Optimized for low energy consumption
Batch vs. continuous operation
Batch processing capability
Cleaning method
Manual loading/unloading safety
Safety features
Loading outside safety zone

Physical Characteristics


Machine footprint
Compact
Control panel type
Proface 3.5 colors
Reel width
Up to 800 or 1200 mm
Reel diameter
1000 mm
Core diameter
100 mm

Custom Options


Compact footprint
Compact machine easy to integrate
Control panel type
Proface 3.5 colors
Integration possibilities
Easy integration with palletizing systems
