Fruit bin tipper for processing intake
Efficiently transfer fruits and vegetables from standard bins into your processing line with a smooth hydraulic operation, minimizing manual handling and ensuring gentle, consistent flow into washers or sorters.

Tips and Empties Fruits and Vegetables
The GKE Bin Tipper from Kreuzmayr Maschinenbau GmbH is engineered to streamline your fruit and vegetable processing operations. Built entirely of stainless steel, this robust machine offers efficient tipping and emptying of bins into washers or conveyors, reducing manual handling and increasing throughput. Its hydraulic or cable winch system smoothly raises bins, making it perfect for processing fruits like apples, pears, quinces, and vegetables such as carrots. With variable tipping heights and stepless hydraulic control, it accommodates various bin sizes, ensuring seamless integration into existing lines. Capable of handling a wide range of capacities, the GKE Bin Tipper supports continuous operation, making it a valuable asset in food processing and agricultural industries. The compact, plug-in design ensures easy cleaning and low maintenance, while the straightforward operation simplifies workflow and reduces downtime.
Benefits
- Enhances productivity by efficiently tipping and emptying bins with minimal manual intervention.
- Minimizes labor costs with easy-to-use hydraulic or cable winch operation.
- Reduces maintenance needs with durable, stainless steel construction.
- Improves integration capabilities with adjustable tipping heights for varied bin sizes.
- Facilitates quick and easy cleaning, ensuring reduced downtime and fast transitions.
- Applications
- Pears,Apples,Citrus fruits,Pomace,Purées,Fruits,Vegetables,Juices,Quinces,Carrots
- End products
- Citrus juice,Vegetable-based purées,Apple juice,Fruit purée,Pear juice,Quince jelly,Carrot juice,Freshly washed and sorted fruits and vegetables,Pomace feed,Fruit juice,Citrus-based beverages
- Steps before
- Harvesting,Transporting,Storing,Loading
- Steps after
- Cleaning,Sorting,Washing,Grinding
- Input ingredients
- apples,pears,quinces,carrots,fruits,vegetables,plastic crates,wooden crates
- Output ingredients
- cleaned fruits,cleaned vegetables,press residues,pomace
- Market info
- Kreuzmayr is known for manufacturing high-quality, industrial juicing and pressing equipment. They specialize in engineered-to-order solutions, offering expertise in processing fruits and vegetables, with a reputation for reliability and innovation in the food and beverage industry.
- Dimensions
- 1600x1480x1220 mm
- Dump high
- 850/1000/1200 mm
- Discharge width
- 500 mm
- Tilted high
- 2420/2625/2835 mm
- Duration of each swivel process
- 15 sec
- Weight
- 350 kg
- Electrical connection
- 400 V / 50 Hz
- Electrical connected load
- 2.2 kW
- Working width
- 560 mm
- Capacity
- up to 8000 kg/h
- Electrical connected load
- 0.37 kW
- Electrical connection
- 400 V / 50Hz
- Available sorting area
- 2000x600 mm
- Capacity
- up to 5000 kg/h
- Dimensions
- 2500x600 / 3000x600(800) / 3500x600 / 4000x800 mm
- Electrical connected load
- 0.55 kW/h (for the biggest machine)
- Electrical connection
- 400 V
- Dimensions
- 2500x1600 mm
- Width conveyor belt
- 500 mm
- Power supply
- 3x400 V
- Electrical power
- 1.1 kW
- Transport area
- 2000x300 to 6000x300 mm
- Capacity
- 1000 to 3000 kg/h
- Electrical Connection
- 400 V
- Electrical power
- 1.5 kW
- Working Mechanism
- Hydraulic or Cable Winch Tipping
- Integrated Steps
- Pre-cleaning,Sorting,Transport
- Automation Level
- Manual Operation with Switch
- Batch vs. Continuous Operation
- Continuous with Adjustable Flow
- Cleaning Method
- Brush Cleaning with Spray Unit
- Energy Efficiency
- Low Power Consumption
- Changeover Time
- Quick Changeover
- Abrasion resistance
- Stainless steel construction
- Biological compatibility
- Food-safe plastic
- Cleanability
- Easy and quick cleaning
- Corrosive resistance (e.g. acids)
- Stainless steel construction
- Density/particle size
- Varies with fruit type
- Fruit Type Compatibility
- Apples,pears,quinces,carrots,etc.
- Machine Dimensions
- 1600x1480x1220 mm
- Dump Height
- 850/1000/1200 mm
- Discharge Width
- 500 mm
- Tilted Height
- 2420/2625/2835 mm
- Weight
- 350 kg
- Material Construction
- Stainless Steel
- Control panel type
- Button switch
- Material
- Stainless steel
- Discharge method
- Hydraulic or cable winch
- Foot support
- Height-adjustable feet
