Disc filter for drying and filtering fine solids
Achieve unparalleled dryness and efficiency in fine solids processing with high-pressure and continuous operation, optimizing dewatering and lowering thermal drying costs for mineral and chemical producers.
Filters and Dewaters Fine Particulate Suspensions
The BoHiBar Disc Filter from BOKELA offers a robust solution for continuous pressure filtration, excelling in applications like alumina processing, coal production, and mineral dewatering. This system utilizes hyperbaric filtration, operating within a sealed pressure vessel to achieve pressure differences up to 6 bar. The unique design ensures efficient filtering and dewatering of fine suspensions, producing dry solids with significantly reduced residual moisture.
The equipment’s applications span across industries, handling end-products such as aluminum hydroxide, activated carbon, and iron concentrates. Available with filter areas up to 168 m², the BoHiBar Disc Filter supports high throughput, accommodating large volumes of slurry and cake processing.
Automation is seamless with its PLC-controlled system, featuring automated startup, shutdown, and cleaning procedures. The integration of steam pressure filtration reduces residual moisture further, while innovative wear protection components and manhole access ensure low maintenance and high availability.
Engineered for flexibility, the filter is constructed from materials resistant to corrosion, supporting longevity even in harsh chemical environments. With capabilities for customization, BOKELA provides comprehensive engineering support tailored to your filtration needs, ensuring reliable and efficient operation.
Benefits
- Increases throughput and reduces handling time with continuous operation.
- Achieves ultra-low residual moisture, enhancing end-product quality and marketability.
- Lowers operational costs by minimizing energy use and eliminating the need for thermal drying.
- Ensures long-term reliability and reduced maintenance with wear-resistant components.
- Provides flexible processing for a wide range of industrial applications.
- Applications
- Tailings,Coal,Chemical and pharmaceutical sector,Iron ore,Alumina,Base metals,Ores and minerals
- End products
- Activated carbon,Aluminum hydroxide,Copper concentrates,Rare earth elements,Mineral concentrates,Sodium hydroxide production residues,Metallurgical grade coal,Bauxite residue,Zinc tailings,Chemical catalysts,Pharmaceutical excipients,Iron concentrates,Sulfuric acid production by-products
- Steps before
- Grinding,Slurry Preparation,Suspension Creation
- Steps after
- Drying,Recycling,Product Handling,Transport
- Input ingredients
- suspension,fine-grained products,concentrates from ore,coal,mineral processing tailings,iron ore,base metals,alumina,bauxite residue
- Output ingredients
- dry solids,filtered cake,recyclables,low residual moisture,dry bauxite residues,filtered product
- Market info
- BOKELA is known for its expertise in engineering and manufacturing filtration technology and equipment, particularly for solid-liquid separation processes in various industries, offering innovative, high-performance solutions with a strong reputation for reliability and efficiency.
- Filtration Pressure Difference
- Up to 6 bar (g)
- Filter Area
- Up to 168 m² per filter unit
- Disc Diameter
- 3.2 m
- No. of Discs
- 3 / 6 / 12
- Pressure Vessel Diameter
- 4.5 m vertical / 4.8-5 m horizontal
- High Solid Throughput
- Yes
- Residual Moisture
- Extremely low with steam pressure filtration
- Automation
- Fully automatic
- Steam Pressure Filtration
- Available
- Continuous Operation
- Yes
- Space Requirement
- Minimal Footprint
- Dewatering Method
- Steam and Compressed Air
- Working Mechanism
- Continuous Rotary Filter
- Filtration Method
- Hyperbaric Filtration
- Process Type
- Continuous Operation
- Pressure Capacity
- Up to 7 bar (a)
- Automation Level
- Fully Automated
- Steam Pressure Filtration
- Available
- Cleaning Method
- Cleaning in Place (CIP)
- Connectivity
- Integrated with SCADA
- Machine Footprint
- Minimal footprint
- Filter Area
- Up to 168 m² per filter unit
- Disc Diameter
- 3.2 m
- No. of Discs
- 3 / 6 / 12
- Pressure Vessel Design
- Vertical / Horizontal
- Pressure Vessel Diameter
- 4.5 m / 4.8-5 m
- Discharge Method
- Reverse blast of compressed air
- Control panel type
- Automated/PLC
- Integration possibilities
- SCADA/PLC
