Cloth media filter for wastewater treatment
Achieve reuse-quality water with continuous filtration, even during backwash, through a high-performance cloth media filter that captures solids down to less than 10 microns.
Captures and Polishes Wastewater for Reuse
The AS-H Iso-Disc from Alfa Laval is a cloth media wastewater filter designed for municipal and industrial applications. Its unique cloth media captures solids down to less than 10 microns, delivering reuse-quality and Title 22 certified water. Operating on a continuous and fully automatic basis, it ensures uninterrupted filtration with a gravity-driven, outside-to-inside flow through submerged media, maximizing the active filtration area. This system is commonly employed in applications like municipal and industrial wastewater treatment, water reuse, and surface water polishing, resulting in treated effluent and polished water. Its robust engineering features corrosion-resistant stainless steel or non-metallic materials, suitable for various operational environments. The Iso-Disc fits easily into existing basins with minimal retrofitting, requiring just a 30 cm water column for driving force. Moreover, its maintenance is streamlined through individual filter element monitoring, quick plate removal for sampling, and efficient backwashing during operation. Configurable for expansion, it supports both square and rectangular configurations, adapting to various installation needs.
Benefits
- Ensures consistent water quality compliance with Title 22 certification for reuse applications.
- Minimizes maintenance downtime with individual filter element monitoring and easy access for maintenance.
- Maximizes active filtration area with continuously submerged media, enhancing efficiency.
- Adapts to existing infrastructure, reducing retrofit costs with flexible plate configurations.
- Operates continuously, maintaining high throughput without interrupting filtration processes.
- Applications
- Surface water treatment,Process streams,Water reuse,Municipal wastewater treatment,Industrial wastewater treatment
- End products
- Tertiary-treated wastewater,Reuse-quality water,Title 22 certified water,Polished surface water,Processed effluent
- Steps before
- Primary Treatment,Secondary Treatment
- Steps after
- Disinfection,Effluent Discharge,Water Reuse,Resource Recovery
- Input ingredients
- municipal wastewater,industrial wastewater,surface water,process streams,influent water
- Output ingredients
- reuse-quality filtrate,tertiary filtration,high-purity filtrate,treated water,effluent
- Market info
- Alfa Laval is renowned for its expertise in heat transfer, separation, and fluid handling technologies, providing innovative, energy-efficient engineered-to-order solutions for various industries including food, marine, and energy.
- Automation
- Fully automatic
- Filtration type
- Cloth media filter
- Micron filtration
- Less than 10 microns
- Flow direction
- Outside-to-inside
- Backwash system
- Bi-directional,linear backwash manifold
- Driving force
- 30 cm water column
- Materials used
- Stainless steel or non-metallic
- Capacity for solids capture
- Capable down to less than 10 microns
- Filtrate quality certification
- California Title 22 Water Reuse Certification
- Installation type
- Square or rectangular cassettes
- Footprint-to-flow ratio
- Small
- Working Mechanism
- Gravity driven,continuous operation
- Integrated Steps
- Filtration and backwashing
- Flow Type
- Outside-to-inside flow
- Automation Level
- Fully automatic
- Backwash Process
- Dynamic,bi-directional,linear backwash manifold
- Filtration Media
- Submerged cloth media
- Maintenance Flexibility
- Individual filter element monitoring and maintenance
- Corrosion resistance
- Stainless steel / Non-metallic materials
- Cleanability
- Easy to maintain with automatic backwashing
- Biological compatibility
- Suitable for wastewater treatment
- Abrasion resistance
- Cloth media durability
- Machine footprint
- Small footprint-to-flow ratio
- Tank shape and size
- Square and rectangular cassettes
- Feed/discharge method
- Gravity driven,outside-to-inside flow
- Material
- Corrosion-resistant stainless steel or non-metallic
- Filtration area
- 100% active filtration area
- Filter Plate Size
- Square / Rectangular
- Installation Configuration
- Flexible for retrofits and new installations
- Tank Material
- Pre-fabricated carbon steel / Stainless steel tanks
- Structure Compatibility
- Concrete structure / Supplied by others
- Filter Media Replacement
- Replaceable cloth media
- Filter Design
- Allows for individual visual assessment and sampling
- Corrosion-Resistant Materials
- Stainless steel / Non-metallic materials
