Automatic pomegranate press

Optimize your juice production with high-speed processing, delivering fresh, pulpless juice with minimal waste in seconds.

Extracts and Presses Pomegranate and Citrus Juices

The Cancan® Automatic Pomegranate Press Model 603 is engineered by Cancan for those in the food and beverage service industries seeking a compact, efficient solution to juice extraction challenges. This machine utilizes a high-speed hydraulic pressing mechanism, enabling rapid juice extraction while minimizing waste. Capable of processing up to six citrus fruits per minute, the Model 603 is ideal for busy environments such as restaurants, cafeterias, and juice bars, ensuring consistent output of beverages such as pomegranate, citrus blend, and orange juice.

Featuring a dual-strainer system, it allows for pulp control, offering users the flexibility to serve juice to varying customer preferences. The machine’s automatic operation integrates smoothly into existing workflows, prioritizing safety with built-in safety switches to prevent accidents. With stainless steel construction, it provides durability and resistance to corrosion, ensuring longevity in demanding settings. The Model 603 supports easy cleaning with a spare upper strainer, enabling seamless transitions between tasks, enhancing operational efficiency.

Benefits

  • Optimizes space usage with a compact design suitable for narrow work areas.
  • Enhances productivity with rapid juice extraction for high-demand environments.
  • Ensures user safety through integrated safety switches preventing operation when open.
  • Offers customizable juice consistency with a dual-strainer system for pulp control.
  • Supports efficient operations with easy-to-clean components, minimizing downtime.

General


Applications
Beverages,Restaurants,Catering services,Juice bars,Cafeterias,Food and beverage service,Juices,Hospitality
End products
Citrus blend juice,Pomegranate juice,Lemon juice,Orange juice,Grapefruit juice,Tangerine juice,Lime juice
Steps before
Fruit Preparation,Washing,Sorting
Steps after
Juice Collection,Servicing,Maintenance,Cleaning
Input ingredients
pomegranate,lime,orange,grapefruit,tangerine,lemon,citrus fruits
Output ingredients
juice,pomegranate juice,citrus juice,fruit juice,mixed fruit juice
Market info

Technical Specifications


Power Rating
220-240 V,50-60 Hz,0.55 kW,4.5 A
Squeezing Capacity
6 pcs/min
Pressing Plate Size
5.1 x 9.5 in
Weight
110.2 lbs / 50 kg
Size (W x D x H)
11.8 x 16.3 x 26.8 in
Squeezing Time
8 seconds

Operating Characteristics


Automation level
Automatic
Batch vs. continuous operation
Batch
Squeezing time
8 seconds
Multi-fruit compatibility
Yes
Safety features
Safety switch
Changeover time
Minimal with spare strainer
Energy efficiency
0.55 kW
Pulp separation
Double strainer
Material handling
Hydraulic pressing

Material Compatibility


Abrasion resistance
High
Corrosive resistance (e.g. acids)
High
Biological compatibility
Food-grade stainless steel
Cleanability
Easy to clean surfaces
Density/particle size
N/A

Product type Characteristics


Use environment
Hotel,Restaurant,Commercial Center,etc.

Physical Characteristics


Machine size (W x D x H)
11.8 x 16.3 x 26.8 in
Machine weight
110.2 lbs / 50 kg
Pressing plate size
5.1 x 9.5 in
Cup reservoir height
6.7 in

Custom Options


Compact footprint
Designed for narrow working areas
Control panel type
Automatic operation
Squeezing options
Mixed squeezing and individual fruit selection
Safety features
Cover with safety switch
Strainer options
Double strainer for less or more pulp
Material
German Stainless Steel
