Ashing furnace for sensitive analytical applications
Ensure analytical purity and safely test materials by containing corrosive vapors and avoiding contamination from traditional chamber materials, ideal for sensitive mineral and elemental analysis.
Contains Corrosive Vapours and Processes Diverse Samples
The GSM 11/8 from Carbolite Gero is an ashing furnace designed to tackle the challenges of mineral and elemental analysis with its unique fused quartz chamber. This construction minimizes contamination from alumina or silica dust, making it ideal for testing geological, metal, and chemical samples. The furnace excels in containing aggressive and corrosive vapours such as sulphuric, nitric, and hydrochloric acids, maintaining sample integrity during high-temperature processes up to 1100°C.
Working on a batch operation mode, the GSM 11/8 uses a single ramp and process timer controlled by the Carbolite Gero 301 controller, allowing for precise temperature management. The furnace integrates seamlessly into laboratories and industrial research operations, especially in chemical and environmental testing facilities. Optional features, including a gas inlet for modified atmospheres and advanced digital controllers, enhance its versatility.
Additionally, the furnace supports a range of applications from ashing to heat treatment of various solid, liquid, and gaseous samples. It is constructed for easy integration into both manual and automated production lines, with customizable configurations available to meet specific industry standards and operational needs.
Benefits
- Ensures contamination-free analysis with a fused quartz chamber, essential for accurate results in sensitive applications.
- Offers superior containment of corrosive vapours, protecting samples and prolonging equipment life.
- Provides precise temperature control up to 1100°C, critical for consistent testing outcomes.
- Integrates easily with existing laboratory setups, enhancing operational efficiency.
- Customizable options support diverse applications, adapting to specific industry requirements.
- Applications
- Heat treatment,Laboratory testing,Corrosive vapour containment,Elemental analysis,Mineral analysis,Material testing
- End products
- Geological samples,Cement samples,Sediment samples,Rock samples,Chemical compounds,Ceramic products,Soil samples,Industrial waste samples,Glass samples,Metal alloys
- Steps before
- Sample Preparation,Grinding,Milling
- Steps after
- Chemical Analysis,Material Testing
- Input ingredients
- samples for analysis,aggressive vapours,corrosive vapours,fused quartz,sulphuric acid,nitric acid,hydrochloric acid
- Output ingredients
- analyzed samples,uncontaminated test results,contained vapours
- Market info
- Carbolite Gero is renowned for designing and manufacturing high-temperature laboratory and industrial furnaces and ovens, offering expertise in heat treatment solutions, with a reputation for quality, reliability, and precise thermal processing across various industries.
- Maximum Operating Temperature
- 1100°C
- Controller Type
- Carbolite Gero 301
- Chamber Material
- Fused Quartz
- Heating Element Configuration
- 4 sided heating (2 sides,roof,hearth)
- Corrosive Vapour Containment
- Superior containment for H2SO4,HNO3,HCl
- Gas Inlet
- Optional,for modified atmospheres
- Sample Trays,Racks
- Optional
- Maximum operating temperature
- 1100°C
- Gas containment
- Improved with fused quartz liner
- Corrosive vapor containment
- Superior containment
- Heating method
- 4 sided heating (2 sides,roof,hearth)
- Automation level
- Manual to full automation
- Gas inlet option
- Available for modified atmospheres
- Corrosive resistance (e.g. acids)
- Superior containment of H2SO4,HNO3,HCl
- Dust contamination prevention
- Fused quartz chamber minimizes Al2O3 and SiO2 contamination
- Heating Element Placement
- 4 sided (2 sides,roof,hearth)
- Chamber Material
- Fused Quartz
- Maximum Operating Temperature
- 1100°C
- Door Type
- Moulded ceramic fibre door plug
- Control panel specification
- Single ramp to set-point,process timer
- Sample trays,racks
- Customizable sample holding options
