Automatic case forming for Rsc cartons

Optimize your beverage packaging line with a compact, integrated solution for efficiently forming and handling RSC cartons, ensuring precise bottle insertion and secure closure.

Forms, Inserts, and Secures Bottles in Cartons

The Serie Flexi from APE Impianti is a comprehensive packaging system designed to enhance bottling operations for wine, beer, and beverage producers. Featuring the innovative AXIPACK technology, this equipment seamlessly integrates into high-speed production lines, offering unmatched flexibility for varying facility layouts and space constraints. The Serie Flexi comprises several specialized modules, including the FORM 2010 for carton forming, INCA 180 for bottle insertion, and the CH 2010 for carton closing, ensuring precise control and efficient handling of up to 12,000 bottles per hour. With brushless motor technology, it delivers precise motion control, optimizing energy usage and reducing downtime. The system’s PLC-driven automation allows for customizable configurations, enabling quick format changes via a single operator panel. Tailored for reliability and minimal maintenance, the Serie Flexi is ideal for producing wine packaging cartons, beer bottle crates, and beverage shipping cases, while offering configurations suitable for glass and plastic bottle packaging.

Benefits

  • Achieves high-speed packaging with accurate bottle insertion, enhancing line productivity.
  • Adapts seamlessly to different production layouts, maximizing space efficiency.
  • Minimizes energy use with brushless motor technology for cost-effective operations.
  • Streamlines changeovers with automated format adjustments, reducing downtime.
  • Supports diverse packaging needs, from glass bottle crates to beverage carton boxes.

General


Applications
Beer bottles,Plastic bottles,Beverage boxes,Beverage packaging,Wine bottles,Returnable glass bottles,Glass bottles
End products
Beer bottle crates,Beverage carton boxes,Plastic bottle packaging,Returnable glass bottle crates,Glass bottle shipping cartons,Wine packaging cartons,Beverage shipping cases
Steps before
Bottle preparation,Carton selection
Steps after
Sealing,Palletizing
Input ingredients
bottiglie,cartone RSC,casse in plastica
Output ingredients
cartone formato e chiuso,bottiglie incartonate,casse con bottiglie
Market info

Technical Specifications


Speed
Up to 12,000 bottles/h
Production Capacity
6,000 - 12,000 bottles/h
Carton Style
RSC - AMERICANO
Automation
Automatic,PLC-controlled
Motor Type
Brushless motors
Changeover Time
Fast,automated
Container Type
Bottles
Configuration
Combinable with forming and packing units
Control System
Single operator panel
Flexibility
High,due to AXIPACK technology

Operating Characteristics


Integrated steps
Forming,inserting,closing
Changeover time
Quick and automated
Automation level
PLC-controlled
Flexibility
Completely modular system
Batch vs. continuous operation
Inline continuous
Speed
Up to 12,000 bottles/hour
Motion control
Brushless motors

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Product type Characteristics


Bottle Size
330ml / 500ml / 750ml
Carton Type
RSC – AMERICANO
Hot Glue Closure
Bottom and top flaps of cartons
Insert Type
Plastic / Cardboard dividers

Physical Characteristics


Compact footprint
Minimum space required,integrated system
Control panel type
Single operator panel
Machine footprint
Space-saving design,integrated with incartonatrice

Custom Options


Control panel type
Single operator panel
Integration possibilities
Combinable with carton packer and case packer
Footprint
Compact
Component customization
Brushless motors,radial motion control
Format change capabilities
Automated format change via operator panel
Combinability
Fully modular with AXIPACK technology
